14
Before Use
SQT0628 (ENG)
Press [LVF] to switch between the Monitor and Viewfinder.
•
The monitor/viewfinder will switch as follows:
∫ Diopter adjustment
Adjust the diopter to suit your vision so that you can see the
viewfinder clearly.
Look at the display on the viewfinder and rotate the diopter
adjustment dial to where the screen is in focus.
A Diopter adjustment dial
1 Attach the battery paying
attention to the direction of
the battery.
2 Connect the AC cable.
•
The [CHARGE] indicator A
lights up and charging
begins.
∫ About the [CHARGE]
indicator
•
When the [CHARGE] indicator flashes
– The battery temperature is too high or too low. It is recommended to charge the battery again
in an ambient temperature of between 10 oC and 30 oC.
[LVF] button (Switching the Monitor/Viewfinder)
Automatic viewfinder/
monitor switching
¢
Viewfinder display
¢
Monitor display
¢ If [Eye Sensor AF] in the [Custom] menu is set to [ON], the camera automatically adjusts
the focus as the eye sensor is activated.
Charging the Battery
On: Charging.
Off: Charging has completed.
(Disconnect the charger from the electrical socket and detach the
battery after charging is completed.)
