1 Mode dial (P19)
2 Camera ON/OFF switch (P16)
3 Status indicator (P16)
4 Wi-Fi
®
connection lamp (P54)
5
Focal length scale (35 mm film camera
equivalent)
• Indicates values for the [3:2] aspect
ratio. (When recording motion pictures,
refer to the focal length displayed on
the screen.)
6 [Wi-Fi] button (P54)/[Fn2] button
7 [Fn1] button
8 Motion picture button (P20)
9 Shutter button (P20)
10 Zoom lever (P52)
11
Self-timer indicator (P47)/
AF Assist Lamp
12 Flash (P53)
13
Stereo microphone
• Be careful not to cover the microphone
with your finger. Doing so may make
sound difficult to record.
14
Hot shoe (Hot shoe cover)
• Keep the Hot Shoe Cover out of reach
of children to prevent swallowing.
15
Drive mode dial
Single (P44):
Burst (P45):
Auto Bracket (P46):
Self-timer (P47):
Time Lapse/Animation (P47, 49):
16
Flash open lever (P53)
• The flash opens, and recording with the
flash becomes possible.
17 Eye Cup
18 Viewfinder (P14)
19 Eye sensor (P14)
20 Diopter adjustment dial (P14)
21 Lens surface
22 Manual ring (P40, 52)
23 O.I.S. switch (P51)
24 Manual ring selector switch (P39, 52)
25 [MIC] socket
26 Shoulder strap eyelet (P13)
