Panasonic LUMIX DMC-GX8 User Manual

3. Recording Modes
102
Applicable modes:
The effects of aperture and shutter speed can be checked by using the Preview Mode.
•
Confirm the effects of aperture: You can check the depth of field (effective focus range)
before taking a picture by closing the diaphragm blades to the aperture value you set.
• Confirm the effects of shutter speed: Movement can be confirmed by displaying the actual
picture that will be taken with that shutter speed.
When the shutter speed is set for high speed, display in the shutter speed preview will be
displayed like a time-release film. It is used in cases such as stopping the movement of running
water.
1 Set a function button to [Preview]. (P70)
•
The following step is an example in which [Preview] is assigned to [Fn7].
2 Press [Fn7] to switch the effect preview screen.
•
Screen is switched every time [Fn7] is pressed.
A Function button [Fn7]
Depth of field properties
¢1 Recording conditions
¢2 Example: When you want to take a picture with a blurred background etc.
¢3 Example: When you want to take a picture with everything in focus including the background
etc.
Confirm the Effects of Aperture and Shutter Speed (Preview Mode)
Normal recording screen
Aperture effect preview
screen
Aperture effect: ±
Shutter speed effect: —
Shutter speed effect
preview screen
Aperture effect: ±
Shutter speed effect: ±
¢1
Aperture value Small Large
Focus length of the lens Tele Wide
Distance to the subject Near Distant
Depth of field (effective focus range) Shallow (Narrow)
¢2
Deep (Wide)
¢3
A
6KWU6SHHG(IIHFWDGGHG
Fn7
3UHYLHZFRPSOHWHG
Fn7

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
