Panasonic LUMIX DMC-GX8 User Manual

13. Others
372
[Custom]
[Cust.Set Mem.] Registers the current camera settings as custom set. P121
[Silent Mode] Disables operational sounds and output of light at once. P206
[AF/AE Lock]
Sets the fixed content for focusing and exposure when the
AF/AE lock is on.
P166
[AF/AE Lock Hold]
This will set the operation of [AF/AE LOCK] button when
taking a picture with fixed focus or exposure.
P166
[Shutter AF]
Set whether or not the focus is adjusted automatically
when the shutter button is pressed halfway.
P155
[Half Press Release]
The shutter will immediately fire when the shutter button is
pressed halfway.
P155
[Quick AF]
Speeds up the focusing that takes place when you press
the shutter button.
P155
[Eye Sensor AF]
The camera automatically adjusts the focus when the eye
sensor is active.
P45
[Pinpoint AF Time]
Sets the time for which the screen is enlarged when the
shutter button is pressed halfway with Auto Focus Mode
set to [ ].
P152
[Pinpoint AF Display]
Sets whether to display the assist screen that appears
when Auto Focus Mode is set to [ ] in a window or full
screen.
P152
[AF Assist Lamp]
AF assist lamp will illuminate the subject when the shutter
button is pressed half-way making it easier for the camera
to focus when recording in low light conditions.
P156
[Direct Focus Area]
Moves the AF area or MF assist using the cursor button
when recording.
P150,
P161
[Focus/Release Priority] It will set so no picture can be taken when it is out of focus. P157
[AF+MF]
You can set the focus manually after the automatic focus
has finished.
P157
[MF Assist] Sets the display method of MF Assist (enlarged screen). P163
[MF Assist Display]
Sets whether MF Assist (enlarged screen) will appear in a
windowed screen display or in a full screen display.
P160
[MF Guide]
When you set the focus manually, an MF guide that allows
you to check the direction to achieve focus is displayed.
P163
[Peaking]
In-focus portions are highlighted when focus is being
adjusted manually.
P164

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
