Panasonic LUMIX DMC-GX8 User Manual

227
8. Stabilizer, Zoom and Flash
• Do not bring any objects near the flash. The heat and light from the flash may cause the objects
to deform or discolor.
• It may take time to charge the flash if you repeatedly take pictures. You must wait a moment to
take the next picture while the flash icon is blinking red indicating the flash is charging. Take a
picture after the access indication disappears.
• You can set the aperture value, the shutter speed and the ISO sensitivity on the camera even
when attaching the external flash.
• If you use the external flash when the White Balance is set to [ ], finely adjust the White
Balance depending on the picture quality. (P131)
• If you record at close range with a wide angle, light from the flash may be blocked by the lens,
darkening the lower part of the screen.
• The camera will become unstable when attaching the external flash, it is recommended to use
a tripod when taking picture.
• When attaching the external flash, do not hold only the external flash because it may detach
from the camera.
• Even if the external flash is turned off, the camera may enter the external flash mode when the
external flash is attached. Remove the external flash when it is not in use or when you carry it.
• Do not use commercially available external flashes with high-voltage synchro terminals,
reverse polarity or functions that enable them to communicate with the camera. Doing so may
cause the camera to malfunction or operate incorrectly.
• Read the operating instructions of the external flash for details.
When using other commercially available external flashes without
communication functions with the camera
•
It is necessary to set the exposure on the external flash. If you want to use the external flash
in Auto Mode, use an external flash that allows you to set the aperture value and the ISO
sensitivity to match the settings on the camera.
• Set to Aperture-Priority AE Mode or Manual Exposure Mode on the camera and then set the
same aperture value and ISO sensitivity on the external flash. (The exposure cannot be
compensated adequately due to the change on the aperture value in Shutter-Priority AE
Mode and the external flash cannot control the light adequately in Program AE Mode
because the aperture value cannot be fixed.)

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
