247
9. Recording Motion Pictures
Changing the Snap Movie settings
1 Select [SET] in step 2 and then press [MENU/SET].
2 Press 3/4 to select an item and then press [MENU/SET].
Exit the menu after it is set.
Motion pictures recorded with [WHITE-IN] or [BLACK-IN] are displayed as all-white or all-black
thumbnails in Playback Mode.
If you assign [Snap Movie] to [Fn Button Set] (P70), you can display a screen that lets you
switch [Snap Movie] between [ON]/[OFF] by pressing the assigned function button. If you press
[DISP.] while the screen is displayed, you can change the settings for Snap Movie.
[Snap Movie] will be set to [OFF] when you connect to Wi-Fi with [Remote Shooting & View].
This function is not available in the following cases:
[Miniature Effect] (Creative Control Mode)
When the drive mode is set to 4K Photo
[Record
time]
Sets the recording time of motion pictures.
[8SEC]/[6SEC]/[4SEC]/[2SEC]
[Pull Focus]
Allows dramatic imaging expression by shifting focus gradually at the start
of recording.
[ON]/[OFF]
Refer to P248 for details.
[Fade]
Adds a fade-in (gradual appearance) effect to an image and audio as
recording starts or adds a fade-out (gradual disappearance) effect to them
as recording ends.
[WHITE-IN]/[WHITE-OUT]:
Adds a fade-in or fade-out effect that uses a white screen.
[BLACK-IN]/[BLACK-OUT]:
Adds a fade-in or fade-out effect that uses a black screen.
[COLOR-IN]/[COLOR-OUT]:
Adds an effect that fades in from black-and-white to color or an effect that
fades out from color to black-and-white. Audio will be recorded normally.
[OFF]

Table of Contents

Other manuals for Panasonic LUMIX DMC-GX8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-GX8 and is the answer not in the manual?

Panasonic LUMIX DMC-GX8 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeMOS
Image stabilizerYes
Total megapixels21.77 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationBody
Still image resolution(s)5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom- x
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed60 s
Flash modesAuto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio systemMono
Memory slots1
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
Magnification0.77 x
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief21 mm
Scene modesPanorama, Portrait, Landscape (scenery)
Image editingCrop, Rotating
Photo effectsBlack&White, Sepia, Vivid
White balanceATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playbackMovie, Single image, Slide show, Thumbnails
GPS (satellite)No
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)330 shots
Product colorBlack
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth61.3 mm
Width133.2 mm
Height77.9 mm
Weight435 g
Lens length63.6 mm
Lens weight165 g
Lens diameter60.6 mm
Weight (including battery)487 g
