Panasonic LUMIX DMC-GX8 User Manual

317
11. Using the Wi-Fi/NFC Function
∫ Sending images in the camera to a web service with simple operations
Once you send an image, you can send other images to a web service with simple,
smartphone-like operations in an environment where a wireless access point connection is
available.
(The instructions below assume that you are already registered to “LUMIX CLUB”
and the camera has a record of a connection to a wireless access point.)
1 Display an image.
2 Press 4.
(When group pictures are selected, proceed to select
[Upload(Wi-Fi)].)
•
The same operation can be performed by touching [ ].
(When group pictures are selected, touch [ ], and select
[Upload(Wi-Fi)].)
3 Select [Yes] on the confirmation screen.
4 Select a web service.
5 Check the send settings, and select [Set].
•
The camera will connect to a previously connected wireless access point and sends the
image to a web service.
• To change the send setting, press [DISP.]. (P309)
• Step 4, 5 are not necessary when you continue to send another image.
The image will be sent to the same web service with the same send settings.
• To terminate the connection, press [MENU/SET] or operate other controls to exit the
playback screen. You can also terminate the connection by pressing [Wi-Fi]. (P287)
To change the settings for sending images or web service
Terminate the Wi-Fi connection, and follow step
1 and onwards again.
•
You can also change the send settings by pressing [Wi-Fi] while using a Wi-Fi connection.
(P287)
• If the camera has no records of connections to wireless access points that are available, a
screen that asks you to select a connection method is displayed. Select a connection method,
and connect the camera to a wireless access point. (P325)
• When you are not registered to “LUMIX CLUB”, a screen that asks you to acquire a new login
ID is displayed. Acquire a login ID and set a password. (P319)
• When group pictures are displayed continuously, all pictures in the group will be sent. When
group pictures are displayed one by one, the currently displayed picture will be sent.
SUB
MENU

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
