Panasonic LUMIX DMC-GX8 User Manual

397
13. Others
The battery is a rechargeable lithium ion battery. Its ability to generate power comes
from the chemical reaction that takes place inside it. This reaction is susceptible to
the surrounding temperature and humidity. If the temperature is too high or too low,
the operating time of the battery will become shorter.
Always remove the battery after use.
•
Place the removed battery in a plastic bag, and store or keep away from metallic objects (clips,
etc.).
If you drop the battery accidentally, check to see if the body of the battery and the
terminals are damaged.
•
Inserting a damaged battery in the camera will damage the camera.
Bring charged spare batteries when going out.
•
Be aware that the operating time of the battery becomes shorter in low temperature conditions
such as at a ski resort.
• When you travel, do not forget to bring the battery charger (supplied) so that you can charge
the battery in the country that you are traveling in.
Dispose of unusable battery.
•
The battery has a limited life.
• Do not throw the battery into fire because it may cause an explosion.
• The unusable battery should be discarded in accordance with battery recycling laws. Call the
RBRC hotline at 1-800-822-8837 for information.
Do not allow battery terminals to come into contact with metal objects (such as
necklaces, hairpins, etc.).
•
This can cause short-circuiting or heat generation and you may be badly burned if you touch a
battery.
• The [CHARGE] indicator may blink under the influence of static electricity or electromagnetic
wave. This phenomenon has no effects on charging.
• If you use the battery charger near a radio, the radio reception may be disturbed.
Keep the charger 1 m (3.3 feet) or more away from radio.
• The charger may generate whirring sounds when it is being used. This is not a malfunction.
• After use, be sure to disconnect the power supply device from the electrical outlet.
(A very small amount of current is consumed if it is left connected.)
• Keep the terminals of the charger and battery clean.
Battery
Charger

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
