13. Others
400
Recorded data may be damaged or lost if the camera breaks down due to inappropriate
handling. Panasonic will not be liable for any damage caused due to loss of recorded data.
When you use a tripod, make sure the tripod is stable when this unit is attached to it.
You may not be able to remove the card or the battery when using a tripod or unipod.
Make sure that the screw on the tripod or unipod is not at an angle when attaching or detaching
the camera. You may damage the screw on the camera if you use excessive force when
turning it. Also, the camera body and the rating label may be damaged or scratched if the
camera is attached too tightly to the tripod or unipod.
When using this unit with a large-diameter lens, the lens may come into contact with the
pedestal depending on the tripod/unipod. Tightening the screw with the lens and pedestal in
contact with each other may damage this unit or the lens. Therefore it is recommended to
attach the tripod adaptor (DMW-TA1: optional) before mounting on the tripod/unipod.
Read the operating instructions for the tripod or unipod carefully.
If you attach a heavy interchangeable lens (more than about 1 kg/35.3 oz) to the camera body,
do not carry the camera by the shoulder strap.
Hold the camera and the lens when carrying them.
Use the camera as a wireless LAN device
When using equipment or computer systems that require more reliable security than
wireless LAN devices, ensure that the appropriate measures are taken for safety designs
and defects for the systems used. Panasonic will not take any responsibility for any
damage that arises when using the camera for any purpose other than as a wireless LAN
device.
Use of the Wi-Fi function of this camera is presumed to be in countries where this
camera is sold
There is the risk that the camera violates the radiowave regulations if used in countries
other than those where this camera is sold, and Panasonic takes no responsibility for any
violations.
There is the risk that data sent and received via radio waves may be intercepted
Please note that there is the risk that data sent and received via radio waves may be
intercepted by a third party.
About the picture data
About tripods or unipods
About the shoulder strap
Wi-Fi function

Table of Contents

Other manuals for Panasonic LUMIX DMC-GX8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-GX8 and is the answer not in the manual?

Panasonic LUMIX DMC-GX8 Specifications

General IconGeneral
Camera typeMILC Body
Sensor typeMOS
Image stabilizerYes
Total megapixels21.77 MP
Image sensor size- \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationBody
Still image resolution(s)5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom- x
FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed60 s
Flash modesAuto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/3 EV step)
Video resolutions640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio systemMono
Memory slots1
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1040000 pixels
Magnification0.77 x
Viewfinder typeElectronic
USB version2.0
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief21 mm
Scene modesPanorama, Portrait, Landscape (scenery)
Image editingCrop, Rotating
Photo effectsBlack&White, Sepia, Vivid
White balanceATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playbackMovie, Single image, Slide show, Thumbnails
GPS (satellite)No
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3, RAW
Diopter adjustment (D-D)-4 - 3
Power source typeBattery
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)330 shots
Product colorBlack
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth61.3 mm
Width133.2 mm
Height77.9 mm
Weight435 g
Lens length63.6 mm
Lens weight165 g
Lens diameter60.6 mm
Weight (including battery)487 g
