Panasonic Lumix DMC-LX5 User Manual

Preparation
- 18 -
∫ Charging time
•
The indicated charging time is for when the battery has been discharged completely.
The charging time may vary depending on how the battery has been used. The charging
time for the battery in hot/cold environments or a battery that has not been used for a
long time may be longer than normal.
Charging time and number of recordable pictures with the optional battery pack are the
same as above.
∫ Battery indication
The battery indication is displayed on the screen
¢
.
¢ “Screen” refers to the LCD monitor of this unit and the screen of the External Live Viewfinder
(DMW-LVF1; optional) when selected.
[It does not appear when you use the camera with the AC adaptor (optional) connected.]
•
The indication turns red and blinks if the remaining battery power is exhausted. (The status
indicator blinks when the LCD monitor turns off.) Recharge the battery or replace it with a fully
charged battery.
Note
•
The battery becomes warm after using it and during and after charging. The camera also
becomes warm during use. This is not a malfunction.
• The battery can be recharged even when it still has some charge left, but it is not
recommended that the battery charge be frequently topped up while the battery is fully
charged. (Since characteristic swelling may occur.)
• Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the
resulting heat generated.
Charging time Approx. 155 min

Panasonic Lumix DMC-LX5 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1920, 2736 x 2736, 3072 x 2304, 3328 x 1872, 3648 x 2736, 3968 x 2232
Digital zoom	4 x
Optical zoom	3.8 x
Extra/Smart zoom	6.7 x
Focal length range	5.1 - 19.2 mm
Number of diaphragm blades	5
Number of aspheric elements	3
Lens structure (elements/groups)	10/9
Aperture range (F-F)	2 - 3.3
Camera shutter speed	60 - 1/4000 s
Focal length (35mm film equivalent)	24 - 90 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	1 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter interval	0.5 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 4.4 m
Flash range (wide)	0.8 - 7.2 m
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Shade
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.6 V
Battery capacity	1250 mAh
Battery life (CIPA standard)	400 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 5.0 HD Edition, / SILKYPIX Developer Studio 3.1 SE, / QuickTime / Adobe Reader

Weight and Dimensions

Depth	43 mm
Width	109.7 mm
Height	65.5 mm
Weight	233 g
Weight (including battery)	271 g
