Panasonic MFDLTA3BM - Page 95

No. SX-DSV03335 - 93-
R2.0 Industrial Device Solution Business Unit, Panasonic Corporation
Model No.
MBDLN21BL
MBDLT21BM
MBDLN25BL
MBDLT25BM
MCDLN31BL
MCDLT31BM
MCDLN35BL
MCDLT35BM
Power supply input
Single phase
100 V
Single phase/
3 phase 200 V
Single phase
100 V
Single phase/
3 phase 200 V
Maximum output current
12 A
12 A
22 A
22 A
Regenerative resistor
Externally connected
Externally connected
Built-in
Built-in
Auto gain tuning function
Provided
Provided
Provided
Provided
Dynamic brake function
Provided
Provided
Provided
Provided
Operation temperature
0 – 55 C
0 – 55 C
0 – 55 C
0 – 55 C
Control power cable
HVSF 0.75 mm
2
HVSF 0.75 mm
2
HVSF 0.75 mm
2
HVSF 0.75 mm
2
AWG18
AWG18
AWG18
AWG18
Main power supply cable
HVSF
0.75 - 2.0 mm
2
HVSF
0.75 - 2.0 mm
2
HVSF
0.75 - 2.0 mm
2
HVSF
0.75 - 2.0 mm
2
AWG14 - 18
AWG14 - 18
AWG14 - 18
AWG14 - 18
Ground cable
HVSF 2.0 mm
2
HVSF 2.0 mm
2
HVSF 2.0 mm
2
HVSF 2.0 mm
2
AWG14
AWG14
AWG14
AWG14
Motor cable
HVSF
0.75 - 2.0 mm
2
HVSF
0.75 - 2.0 mm
2
HVSF
0. 5 - 2.0 mm
2
HVSF
0.75 - 2.0 mm
2
AWG14 - 18
AWG14 - 18
AWG14 - 18
AWG14 - 18
Inrush current
(Main power supply) (*1)
Max. 7 A
Max. 14 A
Max. 15 A
Max. 29 A
Inrush current
(Control power supply) (*1)
Max. 7 A
Max. 14 A
Max. 7 A
Max. 14 A
Weight
Approx 1.0 kg
Approx 1.0 kg
Approx 1.6 kg
Approx 1.6 kg
Dimensions
Size B
Size B
Size C
Size C
(*1) The current is the value calculated with the voltage as 100 V when the product power input voltage is 100 V
specification and 200 V when the product is 200 V specification.
