Model No.
MDDLT54BM
MDDLT64BM
MEDLT84BM
Power supply input
3 phase 400 V
3 phase 400 V
3 phase 400 V
Maximum output current
15 A
20 A
28 A
Regenerative resistor
Built-in
Built-in
Built-in
Auto gain tuning function
Provided
Provided
Provided
Dynamic brake function
Provided
Provided
Provided
Operation temperature
0-55 ℃
0-55 ℃
0-55 ℃
Control power cable
HVSF 0.52 mm
2
HVSF 0.52 mm
2
HVSF 0.52 mm
2
AWG20
AWG20
AWG20
Main power supply cable
HVSF 2.0 mm
2
HVSF 2.0 mm
2
HVSF 2.0 mm
2
AWG14
AWG14
AWG14
Ground cable
HVSF 2.0 mm
2
HVSF 2.0 mm
2
HVSF 2.0 mm
2
AWG14
AWG14
AWG14
Motor cable
HVSF 2.0 mm
2
HVSF 2.0 mm
2
HVSF 2.0 mm
2
AWG14
AWG14
AWG14
Inrush current
(Main power supply) (*1)
Max．30A
Max．30 A
Max．30 A
Inrush current
(Control power supply) (*1)
Max．48 A
Max．48 A
Max．48 A
Weight
Approx.2.1 kg
Approx2.1 kg
Approx2.7 kg
Dimensions
Size D
Size D
Size E
(*1) The current is the value calculated with the voltage as 400 V when the product power input voltage is
400 V(Control circuit power is 24 VDC) specification .
