6 Work with files
LP-400/LP-V setting categories Setting categories in Laser Marker NAVI smart
Marking character Reference character strings
Character condition Character object settings
Bar code object settingsBar code condition
2D code object settings
Logo condition Graphic object settings
Processing condition Shape object settings
Point radiation condition Point radiation object settings
File settingsGeneral condition
Object group settings
Function setting Function settings
Function settings for all filesCommon setting
Reference character strings for all files
Laser settingsLaser setting
Object group settings
On-the-fly markingTrigger setting
File settings
In the converted files, the parameters for “Marking settings” > “File settings” > “Compatibility
with former models” are the same as the settings of the source data.
Object number and object group number
The object numbers of the marking data are assigned to the numbers shown in the following
table. These numbers can be used with LP-400/LP-V compatible command mode. The
marking data converted from LP-400/LP-V files and data set by LP-400/LP-V compatible
command mode are assigned to the object group number 1000. If another object number
or object group number is set, the marking data cannot be controlled by the LP-400/LP-V
communication commands.
Object type Object number
Character object (reference list type) 1001–1060
Bar code object, 2D code object 1100–1107
Graphic object 1200–1215
Shape object 1300–1315
Point radiation object 1400–1415
Object group 1000
ME-NAVIS2-OP-1 81
