12.1 CHASSIS PARTS LIST
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name& Description Pcs Remark
1 (1) VEG1405 CYLINDER UNIT 1
2 (1) VEH0841 UPPER CYLINDER UNIT 1
3 (1) VDB1256 CYLINDER RETAINER 1
4 (1) VEK7236 CYLINDER STATOR UNIT 1
5 (1) VXP1823 CYLINDER ROTOR UNIT 1
6 (1) VXS0135 EARTH BRUSH UNIT 1
10 (1) VEK8629 CAPSTAN UNIT 1
11 (1) VBS0155 FE HEAD 1
12 (1) VDB1431 TENSION ARM BOSS 1
13 (1) VDB1460 SUPPLY BRAKE ARM BOSS 1
14 (1) VDG1220KIT MAIN CAM GEAR 1
15 (1) VDG1221 CONVERSION GEAR 1
16 (1) VDR0350 SUPPLY/TAKE UP REEL TABLE 2
18 (1) VDV0382 CAPSTAN BELT 1
19 (1) VED0412 A/C HEAD UNIT 1
20 (1) VMX2656 P4 CAP 1
21 (1) VDG1217 WORM GEAR 1
22 (1) VDG1218 WORM WHEEL GEAR 1
23 (1) VDG1219 CENTRE GEAR 1
24 (1) VEM0604 LOADING MOTOR UNIT 1
25 (1) VMD2619 MOTOR BRACKET 1
26 (1) VMB3045 CONVERSION GEAR SPRING 1
27 (1) VMD2620 OPENER PIECE 1
28 (1) VMD2738 LED PRISM 1
29 (1) VML3165 DRIVE RACK ARM 1
30 (1) VML3166 MAIN LEVER 1
31 (1) VML3167 DRIVE MAIN LEVER ARM 1
32 (1) VML3172 SUPPLY SPRING ARM 1
33 (1) VML3176 CONVERSION LEVER A 1
