12.2 CASING PARTS LIST
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name& Description Pcs Remarks
101 (2) VGM1466 TOP PANEL 1 [SUPPLIED FROM MBV]
102 (2) VYP7148 FRONT PANEL UNIT 1 [SUPPLIED FROM MBV]
NV-SD440EG
102 (2) VYP7149 FRONT PANEL UNIT 1 [SUPPLIED FROM MBV]
NV-SD440B/BL
103 (2) VKA0191 LEG 2
104 (2) VKF3037 BLINDER PANEL 1 [SUPPLIED FROM MBV]
105 (2) VMB2521 BLINDER SPRING 1
106 (2) VKF3038 DOOR 1 [SUPPLIED FROM MBV]
107 (2) VMC1289 EARTH SPRING 1
110 (2) RKA0072 FOOT 2 NV-SD440EG
110 (2) RKA0072 FOOT 4 NV-SD440B/BL
111 (2) VMC1065 EARTH SPRING 1
115 (2) VKU0519 BOTTOM PLATE 1
116 (2) VJH1023 JACK PLATE 1 [SUPPLIED FROM MBV]
117 (2) VWJ1284 FLAT CARD CABLE (12P) 1 [SUPPLIED FROM MBV]
P3001 - P501
118 (2) VWJ1281 FLAT CARD CABLE (6P) 1 [SUPPLIED FROM MBV]
P4003 - A/C HEAD
119 (2) VWJ1282 FLAT CARD CABLE (9P) 1 [SUPPLIED FROM MBV]
P2502 - P2901
120 (2) VMJ1283 FLAT CARD CABLE (6P) 1 [SUPPLIED FROM MBV]
P6501 - P7502
B101 (2) XTW3+10TFZ SCREW 4
B102 (2) VHD0168 SCREW 2
B103 (2) VHD0773 SCREW 2
B104 (2) VHD1065 SCREW 3
B105 (2) XTV26+6FR SCREW 1
B106 (2) XTV26+8FR SCREW 3
