4.3.4 PG SHIFTER
ADJUSTMENT/(AUTOMATIC)
TOP PREVIOUS NEXT
PROCEDURES FIP Display
Press the FF and EJECT keys simultaneously for 3 seconds.
Press the FF and EJECT keys simultaneously more twice.
Press the EJECT key for 3 seconds.
Press the CH UP key once.
Insert the Alignment Tape.
(PAL: VFJ81215H3F)
(NTSC: VFM8080HQFP)
This adjustment is automatically started. (During the adjustment, the picture will be appeared on the monitor.)
When this Adjustment is terminated, the following operation will be activated.
Adjustment completed: The tape will be ejected.
Adjustment incompleted: "F2*" is indicated on the FIP.Check the Servo/System Control circuit and Cylinder Unit.
To release Service Mode, press the FF and EJECT keys simultaneously 6 times until the normal indication on the FIP.
Fig. E3
•@
