Panasonic NV-SD440EG/ - Page 52

INPUT CONDITION OUTPUT RESULT
POWER AV2 TV/ EE/ OSD INPUT AV2 AV1 AV2 AV1 RGB VCR VCR
SELECT VTR VV ON(H) CH PB(H) OUT OUT PB(H) SW IN OUT
P.ON EXT TV EE L NORMAL TUN --- VTR OUT VTR OUT L OFF TUN TUN
C+ TUNER --- VTR OUT VTR OUT L OFF TUN TUN
AV1 --- VTR OUT VTR OUT L OFF AV1 AV1
AV2 --- VTR OUT VTR OUT L ON AV2 AV2
AV3 --- VTR OUT VTR OUT L OFF AV3 AV3
SAT.NOR TUN --- VTR OUT VTR OUT L OFF SAT.TUN SAT.TUN
SAT.C+ TUN --- VTR OUT VTR OUT L OFF SAT.TUN SAT.TUN
H NORMAL TUN --- VTR OUT VTR OUT H OFF TUN TUN
C+ TUNER --- VTR OUT VTR OUT H OFF TUN TUN
AV1 --- VTR OUT VTR OUT H OFF AV1 AV1
AV2 --- VTR OUT VTR OUT H ON AV2 AV2
AV3 --- VTR OUT VTR OUT H OFF AV3 AV3
SAT.NOR TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
SAT.C+ TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
VTR EE L NORMAL TUN --- VTR OUT VTR OUT H OFF TUN TUN
C+ TUNER --- VTR OUT VTR OUT H OFF TUN TUN
AV1 --- VTR OUT VTR OUT H OFF AV1 AV1
AV2 --- VTR OUT VTR OUT H ON AV2 AV2
AV3 --- VTR OUT VTR OUT H OFF AV3 AV3
SAT.NOR TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
SAT.C+ TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
H NORMAL TUN --- VTR OUT VTR OUT H OFF TUN TUN
C+ TUNER --- VTR OUT VTR OUT H OFF TUN TUN
AV1 --- VTR OUT VTR OUT H OFF AV1 AV1
AV2 --- VTR OUT VTR OUT H ON AV2 AV2
AV3 --- VTR OUT VTR OUT H OFF AV3 AV3
SAT.NOR TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
SAT.C+ TUN --- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
VV --- NORMAL TUN --- VTR OUT VTR OUT H OFF TUN PB
C+ TUNER --- VTR OUT VTR OUT H OFF TUN PB
AV1 --- VTR OUT VTR OUT H OFF AV1 PB
AV2 --- VTR OUT VTR OUT H OFF AV2 PB
AV3 --- VTR OUT VTR OUT H OFF AV3 PB
SAT.NOR TUN --- VTR OUT VTR OUT H OFF SAT.TUN PB
SAT.C+ TUN --- VTR OUT VTR OUT H OFF SAT.TUN PB
DECODER TV EE L NORMAL TUN L VTR OUT AV1 IN L OFF TUN TUN
H AV2 IN AV1 IN H ON TUN TUN
C+ TUNER L VTR OUT TUN IN L OFF TUN TUN
H VTR OUT TUN IN L OFF AV2 AV2
AV1 L VTR OUT AV1 IN L OFF AV1 AV1
H AV2 IN AV1 IN H ON AV2 AV2
AV2 L VTR OUT AV1 IN L ON AV2 AV2
H AV2 IN AV1 IN H ON AV2 AV2
AV3 L VTR OUT AV1 IN L OFF AV3 AV3
H AV2 IN AV1 IN H ON AV3 AV3
SAT.NOR TUN L VTR OUT AV1 IN L OFF SAT.TUN SAT.TUN
H AV2 IN AV1 IN H ON SAT.TUN SAT.TUN
SAT.C+ TUN L VTR OUT SAT IN L OFF SAT.TUN SAT.TUN
H VTR OUT SAT IN L OFF AV2 AV2
H NORMAL TUN L VTR OUT AV1 IN H OFF TUN TUN
H VTR OUT AV1 IN H OFF TUN TUN
C+ TUNER L VTR OUT TUN IN H OFF TUN TUN
H VTR OUT TUN IN H ON AV2 AV2
AV1 L VTR OUT AV1 IN H OFF AV1 AV1
H VTR OUT AV1 IN H ON AV2 AV2
AV2 L VTR OUT AV1 IN H ON AV2 AV2
H VTR OUT AV1 IN H ON AV2 AV2
NOTE: THIS TABLE IS ONLY FOR "EG/EC" MODEL
