INPUT CONDITION OUTPUT RESULT
POWER AV2 EE/VV OSD INPUT AV AV1 AV2 AV1 RGB VCR VCR
SELECT ON(H) CH PB(H) OUT OUT PB(H) SW IN OUT
P.ON EXT EE L TUNER ---- VTR OUT VTR OUT L OFF TUN TUN
AV1 ---- VTR OUT VTR OUT L OFF AV1 AV1
AV2 ---- VTR OUT VTR OUT L ON AV2 AV2
AV3 ---- VTR OUT VTR OUT L OFF AV3 AV3
SAT.TUN ---- VTR OUT VTR OUT L OFF SAT.TUN SAT.TUN
H TUNER ---- VTR OUT VTR OUT H OFF TUN TUN
AV1 ---- VTR OUT VTR OUT H OFF AV1 AV1
AV2 ---- VTR OUT VTR OUT H ON AV2 AV2
AV3 ---- VTR OUT VTR OUT H OFF AV3 AV3
SAT.TUN ---- VTR OUT VTR OUT H OFF SAT.TUN SAT.TUN
VV ---- TUNER ---- VTR OUT VTR OUT H OFF TUN PB
AV1 ---- VTR OUT VTR OUT H OFF AV1 PB
AV2 ---- VTR OUT VTR OUT H OFF AV2 PB
AV3 ---- VTR OUT VTR OUT H OFF AV3 PB
SAT.TUN ---- VTR OUT VTR OUT H OFF SAT.TUN PB
DECODER EE L TUNER L VTR OUT TUN IN L OFF TUN TUN
H VTR OUT TUN IN L ON AV2 AV2
AV1 L VTR OUT AV1 IN L OFF AV1 AV1
H VTR OUT AV1 IN L ON AV2 AV2
AV2 L VTR OUT AV1 IN L ON AV2 AV2
H VTR OUT AV1 IN L ON AV2 AV2
AV3 L VTR OUT AV1 IN L OFF AV3 AV3
H VTR OUT AV1 IN L OFF AV3 AV3
SAT.TUN L VTR OUT SAT IN L OFF SAT.TUN SAT.TUN
H VTR OUT SAT IN L ON AV2 AV2
H TUNER L VTR OUT TUN IN H OFF TUN TUN
H VTR OUT TUN IN H ON AV2 AV2
AV1 L VTR OUT AV1 IN H OFF AV1 AV1
H VTR OUT AV1 IN H ON AV2 AV2
AV2 L VTR OUT AV1 IN H ON AV2 AV2
H VTR OUT AV1 IN H ON AV2 AV2
AV3 L VTR OUT AV1 IN H OFF AV3 AV3
H VTR OUT AV1 IN H OFF AV3 AV3
SAT.TUN L VTR OUT SAT IN H OFF SAT.TUN SAT.TUN
H VTR OUT SAT IN H ON AV2 AV2
VV ---- TUNER L VTR OUT TUN IN H OFF TUN PB
H VTR OUT TUN IN H OFF AV2 PB
AV1 L VTR OUT AV1 IN H OFF AV1 PB
H VTR OUT AV1 IN H OFF AV2 PB
AV2 L VTR OUT AV1 IN H OFF AV2 PB
H VTR OUT AV1 IN H OFF AV2 PB
AV3 L VTR OUT AV1 IN H OFF AV3 PB
H VTR OUT AV1 IN H OFF AV3 PB
SAT.TUN L VTR OUT SAT IN H OFF SAT.TUN PB
H VTR OUT SAT IN H OFF AV2 PB
NOTE: THIS TABLE IS ONLY FOR "B" MODEL
