Ref.
No.
Part No. Part Name & Description Remarks
Q3401 B1ABCF000020 TRANSISTOR PT-AE900U
2SD1819A0L TRANSISTOR PT-AE900E
Q3402 B1ABCF000020 TRANSISTOR PT-AE900U
2SD1819A0L TRANSISTOR PT-AE900E
Q3403 B1ABCF000020 TRANSISTOR PT-AE900U
2SD1819A0L TRANSISTOR PT-AE900E
Q3404 2SD1819A0L TRANSISTOR PT-AE900E
Q9603 B1DEGQ000037 TRANSISTOR
Q9604 2SB0710AWL TRANSISTOR
Q9605 2SB0710AWL TRANSISTOR
Q9606 B1DEGM000022 TRANSISTOR
Q9607 B1DEGM000022 TRANSISTOR
Q9608 2SB0710AWL TRANSISTOR
Q9609 2SB0710AWL TRANSISTOR
Q9610 B1DEGM000022 TRANSISTOR
Q9611 B1DEGM000022 TRANSISTOR
Q9614 B1DEGQ000037 TRANSISTOR
[DIODES]
D001 B0EBKR000039 DIODE
D002 B0HCGV000002 DIODE
D003 B0HCKP000004 DIODE
D004 B0JCMG000012 DIODE
D005 MA2J11100L DIODE
D1002 MAZ81500ML DIODE
D1003 MAZ81500ML DIODE
D1005 MAZ80560ML DIODE
D1006 MAZ81500ML DIODE
D1007 MAZ81500ML DIODE
D1008 MAZ80560ML DIODE
D1011 MAZ80560ML DIODE
D1012 MAZ80560ML DIODE
D1013 B3AAB0000038 DIODE
D1024 B3AAB0000038 DIODE
D1105 EZJZ0V171AA VARISTOR
D1107 EZJZ0V171AA VARISTOR
D1110 EZJZ0V171AA VARISTOR
D1117 MAZ80560ML DIODE
D1120 B0JCAE000001 DIODE
D1121 B0JCGD000002 DIODE
D1122 MA3X152E0L DIODE
D1123 MA3X152E0L DIODE
D1124 MA153TX DIODE
D1125 MA704ATX DIODE
D1126 B0JCPD000026 DIODE
D1127 B0JCPD000026 DIODE
D1130 EZJZ0V80008B VARISTOR
D1131 EZJZ0V80008B VARISTOR
D1132 EZJZ0V80008B VARISTOR
D1133 EZJZ0V80008B VARISTOR
D1135 EZJZ0V80008B VARISTOR
D1136 EZJZ0V80008B VARISTOR
D1137 EZJZ0V80008B VARISTOR
D1138 EZJZ0V80008B VARISTOR
D1139 EZJZ0V171AA VARISTOR
D1140 EZJZ0V171AA VARISTOR
D1141 EZJZ0V171AA VARISTOR
D2001 B3AAB0000038 DIODE
D2002 B3AAB0000038 DIODE
D2003 B3AGB0000044 DIODE
D9601 B0HASR000006 DIODE
D9604 MA158TX DIODE
D9605 MA2Z72000L DIODE
D9606 MA158TX DIODE
D9607 MA2Z72000L DIODE
D9608 MA158TX DIODE
D9609 MA2Z72000L DIODE
D9611 MA158TX DIODE
D9612 MA2Z72000L DIODE
D9616 B0ECHP000003 DIODE
D9617 MA2Z72000L DIODE
D9618 MA2Z72000L DIODE
Ref.
No.
Part No. Part Name & Description Remarks
D9619 MA2Z72000L DIODE
D9620 MA2Z72000L DIODE
D9621 MA2Z72000L DIODE
D9622 B0ECHP000003 DIODE
D9623 B0ECHP000003 DIODE
D9624 MA2Z72000L DIODE
D9625 MA2Z72000L DIODE
D9626 MA2Z72000L DIODE
D9627 MA2Z72000L DIODE
D9628 MA2Z72000L DIODE
D9629 B0ECHP000003 DIODE
[COILS]
L001 G0B592H00001 FILTER
L002 G0B592H00001 FILTER
L003 J0JHC0000023 COIL
L004 G0C680KA0134 COIL
L005 G0B301J00001 FILTER
L1002 J0JCC0000168 FILTER
L1003 J0JCC0000168 FILTER
L1004 J0JCC0000168 FILTER
L1005 J0JCC0000168 FILTER
L1006 J0JCC0000168 FILTER
L1011 J0JJC0000022 EMI FILTER
L1012 J0JJC0000022 EMI FILTER
L1014 J0JCC0000168 FILTER
L1015 J0JCC0000168 FILTER
L1016 J0JCC0000168 FILTER
L1017 J0JCC0000168 FILTER
L1018 J0JCC0000168 FILTER
L1019 J0JCC0000168 FILTER
L1021 J0JJC0000022 EMI FILTER
L1022 J0JCC0000168 FILTER
L1023 J0JCC0000168 FILTER
L1024 J0JJC0000022 EMI FILTER
L1025 J0JCC0000168 FILTER
L1026 J0JJC0000022 EMI FILTER
L1027 J0JCC0000168 FILTER
L1032 J0JJC0000022 EMI FILTER
L1034 J0JJC0000022 EMI FILTER
L1035 ELJFA470JFB COIL
L1043 J0JCC0000168 FILTER
L1049 J0JJC0000022 EMI FILTER
L1050 J0JJC0000022 EMI FILTER
L1051 J0JJC0000022 EMI FILTER
L1053 J0JJC0000022 EMI FILTER
L1064 J0JJC0000022 EMI FILTER
L1065 J0JJC0000022 EMI FILTER
L1070 J0JJC0000022 EMI FILTER
L1071 J0JJC0000022 EMI FILTER
L1072 J0JJC0000022 EMI FILTER
L1073 J0JJC0000022 EMI FILTER
L1074 J0JJC0000022 EMI FILTER
L1075 J0JJC0000022 EMI FILTER
L1076 ELJFA470JFB COIL
L1077 J0JJC0000022 EMI FILTER
L1078 J0JCC0000168 FILTER
L1082 J0JCC0000168 FILTER
L1103 J0JCC0000168 FILTER
L1105 J0JJC0000022 EMI FILTER
L1106 J0JJC0000022 EMI FILTER
L1111 J0MAB0000176 COIL
L1112 J0MAB0000176 COIL
L1113 J0MAB0000176 COIL
L1114 J0MAB0000176 COIL
L1117 J0JJC0000022 EMI FILTER
L1120 J0JJC0000022 EMI FILTER
L1121 J0JCC0000168 FILTER
L1122 J0JJC0000022 EMI FILTER
L1123 J0JCC0000168 FILTER
L1124 J0JCC0000168 FILTER
L1125 J0JCC0000168 FILTER
68
PT-AE900U / PT-AE900E
