Chapter 4 Settings — [DISPLAY OPTION] menu
ENGLISH - 101
10) Press the <ENTER> button.
f The conrmation screen is displayed.
11) Press qw to select [OK], and press the <ENTER> button.
Note
f The setting details are displayed in [RESOLUTION] and [VERTICAL SCAN FREQUENCY] of [EDID STATUS].
f The resolution and vertical scanning frequency settings may be required on your computer or video device.
f After conguring settings, your computer or video device or the projector may be required to be restarted.
f Output with resolution and vertical scanning frequency that have been set may not be performed depending on your computer or video
device.
[HDMI IN]
Switch the setting when the external device is connected to the <HDMI IN> terminal of the projector and the
image is not projected correctly.
1) Press as to select [HDMI IN].
2) Press the <ENTER> button.
f The [HDMI IN] screen is displayed.
3) Press as to select [SIGNAL LEVEL].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically sets the signal level.
[64-940]
Select this item when the signal output from the HDMI terminal of an external device (such as a Blu-
ray disc player) is input to the <HDMI IN> terminal.
[0-1023]
Select this item when the signal output from the DVI-D terminal of an external device (such as a
computer) is input to the <HDMI IN> terminal via a conversion cable or similar cable.
Select this item also when the signal output from the HDMI terminal of a computer or other device is
input to the <HDMI IN> terminal.
Note
f The optimal setting varies depending on the output setting of the connected external device. Refer to the operating instructions of the
external device regarding the output of the external device.
f The signal level is displayed for 30 bits of input.
Setting [EDID MODE]
1) Press as to select [HDMI IN].
2) Press the <ENTER> button.
f The [HDMI IN] screen is displayed.
3) Press as to select [EDID MODE].
4) Press the <ENTER> button.
f The [HDMI EDID MODE] screen is displayed.
5) Press qw to switch [EDID MODE].
f The items will switch each time you press the button.
[DEFAULT] Standard setting.
[SCREEN FIT] Changes EDID data according to the [SCREEN FORMAT] setting.
[USER] Sets the [RESOLUTION] and [VERTICAL SCAN FREQUENCY] items to EDID.
f When [DEFAULT] or [SCREEN FIT] is selected, proceed to Step 10).
6) Press the <ENTER> button.
f The [RESOLUTION] screen is displayed.
To Next Page
