Panasonic PT-DZ780

Chapter 6 Appendix — Technical information
176 - ENGLISH
Control details Performance Parameter Default value Remark
INPUT SELECT (when
[DEFAULT] or [USER] is
selected)
No operation 0-7
0 ―
RGB1 8-15
RGB2 16-23
DVI-D 24-31
HDMI 32-39
DIGITAL LINK 40-47
SDI (Only for PT-DZ780) 48-55
No operation 56-127
Execute P IN P, USER1 128-135
Execute P IN P, USER2 136-143
Execute P IN P, USER3 144-151
No operation 152-255
LENS POSITION
No operation 0-31
0
“Move to the home position” is
an operation when [NORMAL] is
selected in [HOME POSITION] of
the [HOME POSITION] screen.
“Move to the ET-DLE030 standard
lens position” is an operation
when [DLE030] is selected in
[HOME POSITION] of the [HOME
POSITION] screen.
Move to the home position
32-63
Move to the ET-DLE030 standard
lens position
No operation 64-255
LENS H SHIFT
LENS V SHIFT
LENS FOCUS
LENS ZOOM
Lens adjustment
(
- ) High speed 0-31
128 ―
(
- ) Low speed 32-63
(
- ) Fine
adjustment
64-95
Operation stop 96-159
Lens adjustment
(+) Fine
adjustment
160-191
(+) Low speed 192-223
(+) High speed 224-255
LENS FUNCTION SELECT
(when [DZ870/DZ21K] is
selected)
No operation 0-15
0
Operate together with LENS
CONTROL.
“Move to the home position” is
an operation when [NORMAL] is
selected in [HOME POSITION] of
the [HOME POSITION] screen.
“Move to the ET-DLE030 standard
lens position” is an operation
when [DLE030] is selected in
[HOME POSITION] of the [HOME
POSITION] screen.
LENS H SHIFT 16-31
LENS V SHIFT 32-47
LENS FOCUS 48-63
LENS ZOOM 64-79
Move to the home position
80-95
Move to the ET-DLE030 standard
lens position
No operation 96-255
LENS CONTROL (when
[DZ870/DZ21K] is selected)
Lens adjustment
(
- ) High speed 0-31
100
Operate together with LENS
FUNCTION SELECT.
(
- ) Low speed 32-63
(
- ) Fine
adjustment
64-95
Operation stop 96-127
Lens adjustment
(+) Fine
adjustment
128-159
(+) Low speed 160-191
(+) High speed 192-223
Execute command action 224-255
POWER
Standby 0-63
128 ―No operation 64-191
Power on 192-255
CUSTOM MASKING
OFF 0-31
255
(Only for PT-DZ780)
To use PC-1, PC-2, and PC-3, the
optional Upgrade Kit (Model No.:
ET-UK20) is required.
PC-1 32-63
PC-2 64-95
PC-3 96-127
No operation 128-255
