1
1-12-2-2-1
1-12. Capacity Table
2. Heating Capacity Performance Data
Type F3 Series
TC :Heating Capacity
IPT :Heating Power Consumption
unit : kW
Outdoor air intake temp(°C W.B.)
Model
Power
Source
Ambient
Return
Air
-16°C -8°C 6°C 10°C 15°C
DB TC IPT TC IPT TC IPT TC IPT TC IPT
S-3650PF3E
(S-3650PF3E(36))
U-36PZ3E5
220V-230V-240V
50Hz 1phase
16 2.6 1.01 3.3 1.08 4.7 1.23 5.1 1.28 5.6 1.35
20 2.5 1.07 3.2 1.15 4.6 1.31 5.0 1.36 5.6 1.44
24 2.5 1.14 3.2 1.23 4.5 1.39 4.9 1.45 5.5 1.53
S-3650PF3E
(S-3650PF3E(50))
U-50PZ3E5
220V-230V-240V
50Hz 1phase
16 3.4 1.41 4.3 1.58 6.0 1.81 6.5 1.92 7.1 2.02
20 3.4 1.51 4.3 1.68 5.9 1.93 6.4 2.04 7.0 2.15
24 3.3 1.60 4.2 1.78 5.8 2.05 6.2 2.17 6.8 2.26
S-6071PF3E
(S-6071PF3E(60))
U-60PZ3E5
220V-230V-240V
50Hz 1phase
16 4.6 1.65 5.5 1.91 7.1 2.36 7.7 2.52 8.1 2.38
20 4.6 1.74 5.4 2.01 7.0 2.48 7.6 2.65 8.0 2.38
24 4.5 1.86 5.3 2.15 6.9 2.65 7.4 2.65 7.9 2.38
S-6071PF3E
(S-6071PF3E(71))
U-71PZ3E5
220V-230V-240V
50Hz 1phase
16 4.7 1.85 5.8 2.10 8.2 2.56 8.8 2.66 8.9 2.50
20 4.7 1.98 5.8 2.24 8.1 2.67 8.7 2.78 8.8 2.50
24 4.5 2.12 5.6 2.40 7.8 2.78 8.2 2.78 8.6 2.50
