2. Settings
SM830256-00_Single_欧州小筺体 TD&SM.indb 16 16/12/28 13:40:31
Setting for Receiver
ScrewPCB cover
Receiver PCB
Main/Sub selector
switch for remote
controllers (4)*
OFF: Main
ON: Sub
Set its address
(1) to (3)
All set at OFF
when shipped
from the factory.
ON
1 2 3 4
Check the settings of the [S003] DIP switch on the
receiver’s PCB.
* Remove the cover from the receiver when
* When using the infrared remote controller and
the wired remote controller in combination,
set the wired remote controller to [Main].
performing the PCB settings.
Setting Address Switches
When more than 1 receiver is installed in the same room, setting addresses prevents interference.
For how to change addresses of wireless (infrared) remote controllers, see “Matching Up Addresses” of wireless (infrared)
remote controllers on page 8-2-1-8.
To change the receiver’s address, remove the cover from the receiver’s PCB and set No.1 to No.3 of the [003] DIP switch
on PCB.
Remote
Controller
Address
Display
Address Address Address Address Address Address Address
ON/OFF
States
ALL
Position of
the receiver’s
address
switch
Receipt is
possible at
all of the
address
positions
1234
1 2 3 4
1 2 3 4
1 2 3 4
1 234
1 2 3 4
OFF ON
1 2 3456
8-3-2. CZ-RWRU3, CZ-RWRU3W
1. Accessories
Supplied accessories
(1)
(1)
Instructions
Operating
repmalC
(1)
Installation
Instructions
8-3-3
