4-6. Automatic Flap Control
The flap position can be selected from 5 positions.
Operating mode Flap position
Cooling/Dry
Fan
1Heating
2 3 4 5
1
2 3 4 5
1
2 3 4 5
The flap will be closed automatically when the indoor unit is stopped.
For 4-Way cassette type (U3), the flap closes once and moves to the set position when the operating
mode is changed.
Do not change the flap position manually.
Only the swing operation can be used.
The swing operation can be set for the flap.
4-7. Filter Sign
When accumulated operating time of the indoor unit reaches the set time, the filter sign appears on
the remote controller. Clean the filter.
See the section “7-2. List of Simple Setting Items, 7-5. Simple Setting Items and Filter sign ON
times for each model”.
After cleaning the filter, press the filter button on the remote controller once. The filter sign turns off.
1
2
3
4
5 (Fully open)
Close
Type U3
NOTE
