4-14
4
Compressor:
ON
Outdoor Fan:
ON
ON
ON
OFF
Fan Speed
OFF
30 sec
4-12-9. Outdoor Fan Motor Operation
Outdoor fan motor is operated with one fan speed only. It starts when compressor starts operation and it stops
30 seconds after compressor stops operation.
according to outdoor piping temperature as following:
OD Pipe Temperature
During cooling operation, and outdoor ambient temperature is below 8°C, outdoor fan speed will be controlled
A 26°C
B 33°C
according to outdoor piping temperature as following:
During above condition, when indoor heat exchanger temperature is below 5°C, the outdoor fan will stop
