How to connect wiring to the terminal
For stranded wiring
(1) Cut the wire end with cutting pliers, then strip the
insulation to expose the stranded wiring about 10 mm
and tightly twist the wire ends.
Stranded wire
Ring
terminal
pressure
Strip 10 mm
(2) Using a Phillips head screwdriver,
(3)
each stripped wire end with a ring pressure terminal.
(4) Place the ring
screwdriver.
pressure terminal, and replace and tighten
the removed terminal screw using a
screw(s) on the terminal board.
Using a ring connector fastener or
remove the terminal
pliers, securely clamp
Ring
Screw and
Special washer
terminal
pressure
Terminal board
terminal
Ring pressure
Screw
washer
Special
Wire
Wire
Examples of shield wires
(1) Remove cable coat not to scratch braided shield.
wires
twist the (2) Unbraid the braided carefully and
covering them with
tightly
shield
tape
together.
an
around them.
Insulate the
insulation tube or
unbraided shield
shield wires by
wrapping insulating
(3) Remove coat of
Insulating tape
signal wire.
Shield mesh
tape
mesh
Insulating
Shield
(4) Attach ring pressure terminals to the
(2). the shield wires insulated in Step
signal wires and
