Ref. No. Part No. Part Name & Description Remarks
50 XTBS26+10J SCREW [M]
52 XTV3+10G-M SCREW [M]
53 XTW3+15T SCREW [M]
54 XTWS3+6T SCREW [M]
55 RMR1350-K WIRE CLIP [M]
56 RMVX0074 LIGHTING PIECE COVER [M]
57 RKFX0111-S CASS. LID [M]
58 RSCX0079-1 REAR SHIELD PLATE [M]
59 RSCX0071 TUNER PACK SHIELD [M]
60 RWJ1103070XX 3P WIRE REMOTE SENSOR [M]
20.4. Electrical Parts List
Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPX0363A CD SERVO P.C.B (SIDE A) [M](RTL)
REPX0363A CD SERVO P.C.B (SIDE B) [M](RTL)
REPX0358B MAIN P.C.B [M](RTL)
REPX0358B PANEL P.C.B [M](RTL)
REPX0358B SENSOR P.C.B [M](RTL)
REPX0358B AC LED P.C.B [M](RTL)
REPX0358B HEADPHONE P.C.B [M](RTL)
REPX0350B DECK P.C.B [M](RTL)
REPX0321C DECK MECHANISM P.C.B [M](RTL)
REPX0350B TAPE EJECT P.C.B [M](RTL)
REPX0357B POWER P.C.B [M](RTL)E/EG
REPX0357C POWER P.C.B [M](RTL)EB
REPX0357B TRANSFORMER P.C.B [M](RTL)E/EG
REPX0357C TRANSFORMER P.C.B [M](RTL)EB
REPX0358B TACT SWITCH P.C.B [M](RTL)
REPX3569A CD LOADING P.C.B [M](RTL)
INTEGRATED CIRCUITS
IC11 C0GAG0000007 IC DRIVER [M]
IC21 C0GAG0000007 IC DRIVER [M]
IC101 LA1833NMNTLM IC IF & MPX [M]
IC102 LC72131MDTRM IC PLL [M]
IC300 C1BB00000747 IC ASP [M]
IC302 C2CBJF000007 IC MICRO-P [M]
IC304 C1BB00000715 IC RDS [M]
IC500 RSN314H41A-P IC POWER AMP HIC [M]
IC501 C0AABB000117 IC OP-AMP (HP AMP) [M]
IC502 C0DAAHG00007 IC SWITCHING REGULAR [M]
IC503 C0CAABE00006 IC [M]
IC600 C0HBB0000033 IC FL DRIVER [M]
IC701 AN22004A-NF IC HEAD AMP [M]
IC702 MN6627931BD IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC704 C3ABMB000027 IC 16M DRAM [M]
IC971 CNB13030R2AU IC PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
109
