11. Procedure for Checking Operation of Individual
Parts of Cassette Mechanism Unit
11.1. Operation Check with Cassette Tape
1. Pull up the EJECT lever using a rubber band. (Cf. Fig. 6)
2. Supply DC5V to MOTOR. ( MOTOR rotates.) (Cf. Fig. 5)
3. Insert a cassette tape to the unit.
75
