Pin
No.
Mark I/O Function
75 H_DO I No Connection
76 H_SEL O No Connection
77 N.C. O No Connection
78 N.C. O No Connection
79 /CD O CD POWER CONTROL
(Active Low)
80 CD_RST O CD Reset Output
81 N.C. O No Connection
82 /RESTSW I CD Limit Switch Input for
the Most inner Point
(Active Low)
83
DECK_LED1
O No Connection
84
DECK_LED2
O No Connection
85
SSEQ_LED
O Super Sound EQ LED
Control
86 RE_LED O MP3/WMA ReMaster LED
Control
87 MOTOR O MOTOR Control Output
L = OFF, H = ON
88 PLUNGER O Deck PLUNGER Control
Output
L = OFF, H = ON
89
DECK_AD1
I DECK AD Input 1
90
DECK_AD2
I DECK AD Input 2
91 REG1 I Region Setting 1
92 KEY3 I KEY3 INPUT
93 KEY2 I KEY2 INPUT
94 KEY1 I KEY1 INPUT
95 VOL_JOG I Volume JOG
96 AVss - Analog Power Supply
Input
(Connect to GND)
97 N.C. O No connection
98 VREF - Reference for A-D (5V)
99 AVcc - Analog Power Supply
Input
100 PLLCE O Tuner PLL Chip Enable
