Panasonic SA-PM28E - Page 95

Pin
No.
Mark I/O Function
47 DCDET I DC Detect Input
48 N.C. - No Connection
49
REMASTER
O Remaster Control
50 PLAY_SW I Play Switch (CR16)
51
STOCK_SW
I Stock Switch (CR16)
52 OPEN_SW I Open Switch (CR16)
53 POS I Position Switch (CR16)
54 BT_SW I Bottom Switch (CR16)
55 M1_R O Changer Motor 1 Reverse
Control
56 M1_F O Changer Motor 1 Forward
Control
57 M2_R O Changer Motor 2 Reverse
Control
58 M2_F O Changer Motor 2 Forward
Control
59 REC O When record circuit is
operating
DURING RECORDING = H
60 KEY_LED O LED switch for key tact
switch
Dimmer ON = L, Dimmer
Off = H
61 PHOTO I PHOTO (SG mechanism
only)
62 Vcc - Power Supply (+5V)
63 N.C. O No Connection
64 Vss - Ground (0V)
65 DMT O Deck Mute at mecha
transition
L = mute OFF, H = mute
ON
66 BP1 O AM beatproof 1 output
(L = BP1, H = BP2
67 VMUTE O No Connection
68 VMODE I No Connection
69 EMPHA I No Connection
70 H_RDY I No Connection
71 H_INT I No Connection
72 V_RST O No Connection
73 H_CLK O No Connection
74 H_DI O No Connection
95
