Panasonic SA-PM28E - Page 94

Pin
No.
Mark I/O Function
15 Xin - 10 MHz Main Clock
16 Vcc - Power Supply (+5V)
17 /NMI - Connect to Vcc (+5V)
18 RMT I Remote Control Input
19 BLKCK I CD Block Clock Input
20 SYNC I AC Failure Detect Input
21 MUTE_H O HIC Mute
22
ECHO_CTL1
O No Connection
23
ECHO_CTR2
O No Connection
24
ECHO_CTR3
O No Connection
25 ECHO_MU O ECHO MUTE
26 ASP_CLK O ASP CLOCK
27 ASP_DAT O ASP DATA
28 L_MUTE O Mute Level
29 SW_LVL1 O No Connection
30 SW_LVL2 O No Connection
31 FL_DOUT /
EFP_TxD1
O Serial Data To FL Driver
(Output)
32 FL_CS1/
EFP_RxD1
I FL Driver Chip Select
(Master)
33 FL_CLK/
EFP_CLK1
I/O Serial Clock To FL Driver
34 CHIP
_SELECT
O Chip Select
35
MDATA_OUT
O CD Command Data
Output
36 STATUS I CD Servo LSI Status Input
37 MCLK O CD Command Clock
Output
38 MLD O CD Command Load
Output
39 /
FL_RESET
O Reset Input (ACTIVE L)
40 MUTE_A O Audio Mute
41 EE_CS /
EFP_ /EPM
O EEPROM Chip Select
42 EE_CLK O EEPROM CLOCK
43 EE_DAT I/O EEPROM DATA
44 RDS_CLK I No Connection
45 RDS_DAT I No Connection
46 PCONT /
EFP_/CE
O Main Transformer Control
Output
94
