Pin
No.
Mark I/O Function
1 CR16
SWITCH
I CR16 Detect Switch
2 PLLCK O Tuner PLL Clock Output
3 PLLDA O Tuner PLL Data Output
4 ST/DO I Tuner IF Data/Stereo Input
5 SD I Tuner Signal Detect Input
6 MBP1 O Microcomputer Beat
Proof Output 1
(CONTROL)
7 MBP2 O Microcomputer Beat
Proof Output 2
(CONTROL)
8 BYTE - External Data Bus Width
Select Input (Connect to
Ground)
9 CNVss /
EFP_CNVss
- Flash Mode Terminal
(Connected To Ground)
10 Xcin - 32.768 kHz Sub Clock
11 Xcout - 32.768 kHz Sub Clock
12 /RESET
EFP_RESET
- Reset Input
(ACTIVE L)
13 Xout - 10 MHz Main Clock
14 Vss - Ground (0V)
