Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of these components, be sure to use only
manufacturers’s specified parts shown in the parts list.
- The parenthesized indications in the Remarks column specify the
areas or color. (Refer to the cover page for area or color.)
Parts without these indications can be used for all areas.
- Warning: This product uses a laser diode. Refer to caution
statements on “Precaution of Laser Diode”.
- Capacitor values are in microfarad ( F) unless specified
otherwise, P=Pico-farads(pF); Farads.
- Resistance values are in ohms, unless specified otherwise, 1K=
1,000(ohms).
- The marking (RTL) indicates that the Retention Time is limited for
this item. After the discontinuation of this assembly in production,
the item will continue to be available for a specific period of time.
The retention period of availability is dependant on the type of
assembly, and in accordance with the lows govening part and
product retention. After the end of this period, the assembly will
no longer be available.
- [M] indicates in the Remarks columns indicates parts that are
supplied by PAVCSG.
- The “(SF)” mark denotes the standard part.
- Reference for O/I book languages are as follows :
Ar : Arabic Cf : Canadian French Cz : Czech Da : Danish
Du : Dutch En : English Fr : French Ge : German
It : Italian Ko : Korean Po : Polish Su : Russian
Sp : Spanish Sw : Swedish Co : Traditional Chinese Cn : Simplified
20.1. Deck Mechanism (RAA4402-S)
20.1.1. Deck Mechanism Parts Location
