Pin No. Mark I/O Function
1 LPD I APC Amp input terminal
2 LD O APC Amp. output terminal
3 VCC I Power source terminal
4 EQSW - Equalizer switch terminal
5 RFOUT O RF summing Amp output
terminal
6 RFIN I AGC input terminal
7 AGC - AGC loop filter
connecting capacitor
terminal
8 AGC
O
AGC output terminal
9 HPF-
AMP
- HPF Amp connecting
capacitor terminal
10 3TOUT O 3TOUT output terminal
11
HPFDET
- Detection system’s HPF
connecting capacitor
terminal
12
OFTCNT
- PFTR detection level
adjustment terminal
13 BDO O BDO output terminal
14 OFTR O OFTR output terminal
15 /RFDET O NRFDET output terminal
16 LDON - LDON terminal
17 GND - Earth terminal
18 EQBST - Equalizer boost
adjustment terminal
19 VREF O VREF output terminal
20 TEN I Amp inverting input
terminal
21 TEOUT O TE amp output terminal
22 FEN I Amp inverting input
terminal
23 FEOUT O FE amp output terminal
24 GCTL - GCTL terminal
25 FBAL I FBAL control terminal
26 TBAL I TBAL control terminal
27 E O Tracking signal input
terminal 1
28 F O Tracking signal input
terminal 2
29 D O Tracking signal input
terminal 4
30 B O Tracking signal input
terminal
2
