Panasonic SA-PM91DEE - Page 139

Ref. No. Part No. Part Name & Description Remarks
CN2817 K1KA09AA0031 9P CONNECTOR [M]
CN5801 RJT119W12V 12P CONNECTOR [M]
CN5805 RJT119W08V 8P CONNECTOR [M]
CN5901 K1KA04BA0061 4P CONNECTOR [M]
CP1301 K1MN05A00019 5P CONNECTOR [M]
CP1902 K1KA09B00058 9P CONNECTOR [M]
CP5802 K1KA12AA0424 12P CONNECTOR [M]
CP5803 K1KA12AA0424 12P CONNECTOR [M]
CS971 RJU071H09M1 9P CONNECTOR [M]
FP8101 K1MN50B00031 50P CONNECTOR [M]
FP8201 K1MN06B00080 6P CONNECTOR [M]
FP8501 K1MN26B00094 26P CONNECTOR [M]
HW601 K1ZZ00000832 CONNECTOR [M]
P611 REX1216Y 3P WIRE [M]
COILS & TRANSFORMERS
L1301 7L1A62N BIAS OCS COIL [M]
L1302 G0C470JA0052 RF CHOKE COIL [M]
L2101 J0JBC0000019 CHIP INDUCTOR [M]
L2201 J0JBC0000019 CHIP INDUCTOR [M]
L2801 G0C3R3JA0027 COIL [M]
L2802 G0A101ZA0028 CHOKE COIL [M]
L2803 G0A200D00002 RF CHOKE COIL [M]
L2804 G0A200D00002 RF CHOKE COIL [M]
L2805 G0A200D00002 RF CHOKE COIL [M]
L2806 G0A101ZA0028 CHOKE COIL [M]
L2807 G0A200D00002 RF CHOKE COIL [M]
L2808 G0C4R7JA0027 COIL [M]
L2809 ELESN220JA CHOKE COIL [M]
L2810 J0JBC0000015 CHIP INDUCTOR [M]
L2811 J0JBC0000015 CHIP INDUCTOR [M]
L2812 J0JBC0000015 CHIP INDUCTOR [M]
L2813 J0JCC0000186 CHIP COIL [M]
L2814 J0JBC0000015 CHIP INDUCTOR [M]
L2815 J0JBC0000015 CHIP INDUCTOR [M]
L2816 J0JBC0000015 CHIP INDUCTOR [M]
L2817 G0C101JA0052 INDUCTOR [M]
L2818 G0C101JA0052 INDUCTOR [M]
L2819 G0C101JA0052 INDUCTOR [M]
L2820 G0C470JA0052 RF CHOKE COIL [M]
L2821 ELJFC2R2KF CHIP COIL [M]
L2822 ELJFC2R2KF CHIP COIL [M]
L2823 ELJFC2R2KF CHIP COIL [M]
L2824 G0C4R7JA0027 COIL [M]
L2825 J0JCC0000120 COIL [M]
L2826 J0JCC0000120 COIL [M]
L2827 J0JCC0000120 COIL [M]
L2828 J0JCC0000120 COIL [M]
L2840 G0A200D00002 RF CHOKE COIL [M]
L2911 ELJFCR39KF CHIP COIL [M]
L5101 G0AR76Y00001 COIL [M]
L5102 G0AR76Y00001 COIL [M]
L5201 G0AR76Y00001 COIL [M]
L5202 G0AR76Y00001 COIL [M]
L5901 G0B371HA0005 LINE FILTER [M]
L8201 G1C100K00020 CHIP INDUCTOR [M]
L8202 J0JCC0000079 CHIP INDUCTOR [M]
L8301 G1C100KA0055 CHIP INDUCTOR [M]
L8302 J0JCC0000079 CHIP INDUCTOR [M]
L8550 G1C100KA0055 CHIP INDUCTOR [M]
T1 ENG07808QF TUNER PACK [M]
T5901 G4C6AFK00008 TRANSFORMER [M]
T5902 G4C2AAJ00007 SUB-TRANSFORMER [M]
COMPONENT COMBINATIONS
Z602 B3RAD0000051 REMOTE SENSOR [M]
Ref. No. Part No. Part Name & Description Remarks
Z971 RGSD12A1445T RADA RESISTOR [M]
Z5901 ERZVA5Z471 ZENER [M]
RELAY
RL5901 K6B1AEA00003 POWER RELAY [M]
OSCILLATORS
X2801 H0A327200115 CRYSTAL OSCILLATOR [M]
X2802 H2B100500004 CERAMIC RESONATOR [M]
X2803 H0H433400002 CRYSTAL OSCILLATOR [M]
X8621 H0J270500085 CRYSTAL OSCILLATOR [M]
DISPLAY TUBES
FL601 A2BD00000112 FL DISPLAY [M]
FL8101 F1H0J1050022 CHIP CAPACITOR [M]
FL8102 F1H0J1050022 CHIP CAPACITOR [M]
FL8103 F1H0J1050022 CHIP CAPACITOR [M]
FL8104 F1J1E1040022 CHIP CAPACITOR [M]
FUSE
F1 K5D801BK0007 800MA FUSE [M]
FUSE HOLDERS
FC1 EYF52BCY FUSE CLIP [M]
FC2 EYF52BCY FUSE CLIP [M]
FUSE PROTECTORS
FP5801 K5G400A00001 RESISTOR [M]
FP5901 K5G402A00025 FUSE PROTECTOR [M]
FP5902 K5G102A00023 FUSE PROTECTOR [M]
HOLDERS
H5804 K1YF08000003 8P WIRE HOLDER [M]
H5902 K1YF12000002 12P WIRE HOLDER [M]
JACKS
JK1000 K4BC04B00060 JK RED/BLACK SPEAKER [M]
JK1001 K4BC04B00059 JK BLUE/HOAR SPEAKER [M]
JK2800 K4BK01B00009 JK 1P RCA [M]
JK2801 K4BK02B00008 JK AUX-IN [M]
JK2802 K1U208B00005 JK [M]
JK2803 K7AABB000004 JK OPTICAL (OUT) [M]
JK2804 K2HC103B0162 JK HEADPHONE [M]
JK2805 K1FB121B0012 JK RGB CONNECTOR [M]
JK5901 K2AA2B000009 JK AC INLET [M]
EARTH TERMINALS
E601 K9ZZ00000424 EARTH TERMINAL [M]
E602 K9ZZ00000424 EARTH TERMINAL [M]
E5801 SNE1004-2 EARTH TERMINAL [M]
E5802 SNE1004-2 EARTH TERMINAL [M]
CHIP RESISTORS
W71 ERJ3GEY0R00V CHIP JUMPER [M]
W72 ERJ3GEY0R00V CHIP JUMPER [M]
W73 ERJ3GEY0R00V CHIP JUMPER [M]
W74 ERJ3GEY0R00V CHIP JUMPER [M]
W81 ERJ3GEY0R00V CHIP JUMPER [M]
W82 ERJ3GEY0R00V CHIP JUMPER [M]
W83 ERJ3GEY0R00V CHIP JUMPER [M]
W84 ERJ3GEY0R00V CHIP JUMPER [M]
W85 ERJ3GEY0R00V CHIP JUMPER [M]
W86 ERJ3GEY0R00V CHIP JUMPER [M]
W87 ERJ3GEY0R00V CHIP JUMPER [M]
139
SA-PM91DEE
