18.1.5. Panel P.C.B.
Ref No.
MODE 1234567891011121314151617181920
CD PLAY -29.5 -29.4 -29.4 -29.5 5.0 3.0 4.1 2.1 0 0 5.1 2.2 2.2 0 -27.5 -31.4 -23.4 -25.4 -23.4 -31.6
STANDBY 00000000000000000000
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -25.4 -29.5 -27.5 -31.7 -25.5 -23.3 -23.4 -29.6 -25.4 -29.5 -21.3 -25.4 -25.4 -27.5 -23.4 -23.4 -25.3 -25.4
-29.5 -27.5
STANDBY 00000000000000000000
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
CD PLAY -25.4 -31.6 -21.3 -25.4 -25.4 -25.4 -31.7 -29.6 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5 -29.5
STANDBY 00000000000000000000
Ref No.
MODE 61 62 63 64
CD PLAY -29.5 -29.5 -29.5 -29.5
STANDBY 0000
Ref No.
MODE E C B E C B E C B E C B E C B
CD PLAY -33.0 5.0 -33.1 -33.0 5.0 -33.1 0 0 0.8 0 3.1 -0.4 0 3.6 0
STANDBY 0 0 0 0 0 0 0 0 0 0 0 0 0 3.8 0
IC601
IC601
IC601
IC601
PANEL P.C.B.
Q601 Q602 Q603 Q611 Q680
18.1.6. Deck P.C.B.
Ref No.
MODE 12345
CD PLAY 6.1 0000
STANDBY 00000
Ref No.
MODE 1234567891011121314151617181920
CD PLAY 0 0.7 5.2 4.4 0 4.9 0 0 0 6.0 0 8.9 00003.80.24.45.1
STANDBY 0 0.3 0.3 0.3 000000000000000.30.3
Ref No.
MODE 21 22
CD PLAY 0.7 0
STANDBY 0.3 0
Ref No.
MODE E C B E C B E C B E C B E C B
CD PLAY 0 0 0.7 0 0 0.7 2.0 1.9 0 0 5.8 0 5.8 0 5.8
STANDBY 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ref No.
MODE E C B E C B E C B E C B E C B
CD PLAY 0 0 0.6 0 4.9 0 0 8.8 0 0 8.8 0 0 0 0
STANDBY 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Ref No.
MODE E C B E C B E C B E C B
CD PLAY 10.0 -0.1 10.0 10.0 0 10.0 0 9.4 -0.2 0 0 0
STANDBY 0.2 -0.2 0.2 0.2 0 0.2 0 0 -0.2 0 0 0
Q1304
IC 1000
IC 1001
Q1101 Q1201 Q1302 Q1303
Q1314 Q1315 Q1316 Q1317
Q1306 Q1307 Q1309 Q1310 Q1312
DECK P.C.B.
IC 1001
18.1.7. Deck Mechanism P.C.B.
Ref No.
MODE 1234
CD PLAY 2.5 4.9 3.8 4.9
STANDBY 0000
IC971
DECK MECHANISM P.C.B.
18.1.8. Scart Terminal P.C.B.
Ref No.
MODE E C B E C B E C B E C B E C B
CD PLAY 6.3 6.3 0 0 0 5.0 0 5.0 0.1 6.9 12.5 6.4 0 0 4.2
STANDBY 0.5 0 0.5 0 0.4 0 0 0 0.6 0.7 0.7 0.6 0 0.5 0
SCART TERMINAL P.C.B.
Q2819 Q2820 Q2821 Q2822 Q2823
