14.2. D-Amp P.C.B.
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 0.1 0.1 2.9 0 -29.3 -29.3 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.3 0 29
STANDBY 2.5 0.1 0.1 2.9 0 -29.3 -21 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.2 0 29
REF NO.
MODE 21 22 23
CD PLAY -0.1 -0.1 2.5
STANDBY -0.1 -0.1 2.5
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 -0.1 -0.1 29 0 -29.3 -29.3 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.3 0 29
STANDBY 2.5 -0.1 -0.1 29 0 -29.3 -29.3 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.3 0 29
REF NO.
MODE 21 22 23
CD PLAY -0.1 -0.1 2.5
STANDBY -0.1 -0.1 2.5
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 2.5 -0.1 -0.1 29 0 -29.3 -29.3 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.3 0 29
STANDBY 2.5 -0.1 -0.1 29 0 -29.3 -29.3 29.3 11 -0.1 -29.5 -17.3 -29.5 -0.1 11 29.3 -29.3 -29.3 0 29
REF NO.
MODE 21 22 23
CD PLAY -0.1 -0.1 2.5
STANDBY -0.1 -0.1 2.5
REF NO.
MODE 1234567891011121314
CD PLAY 0 5.2 5 0 2.7 2.2 0 2.5 2.6 2.6 2.5 0 5.2 5.2
STANDBY 0 5.2 5 0 2.7 2.2 0 2.5 2.6 2.6 2.5 0 5.2 5.2
REF NO.
MODE 1234567891011121314
CD PLAY 2.5 2.6 2.5 0 2.6 0 0 0 0 0 0 0 5.2 5.2
STANDBY 2.5 2.6 2.5 0 2.6 0 0 0 0 0 0 0 5.2 5.2
REF NO.
MODE E C B
ECB ECB ECB ECB
CD PLAY 0 5.2 0
0 5.2 0 0 0 0.7 0 0
0.7 5.2 5.1 4.4
STANDBY 0 5.2 0
0 5.2 0 0 0 0.7 0 0
0.7 5.2 5.1 4.5
REF NO.
MODE E C B
ECB ECB ECB ECB
CD PLAY 0 0 0.7
6.9 16.4 7.4 0 5.2 0 0 0
0.7 0 3.7 0
STANDBY 0 0 0.7
6.9 16.4 7.4 0 5.2 0 0 0
0.7 0 3.7 0
Q5644
Q5604
Q5640 Q5641
Q5642
Q5102 Q5601
Q5602
Q5603
PT760P/PC D-AMP P.C.B.
IC5000
IC5000
IC5200
IC5200
IC5300
IC5300
IC5500
IC5501
Q5101
80
SA-PT760P / SA-PT760PC
