Panasonic SB-WA310 - Page 83

PIN
No.
Mark
I/O
Function
18
AC
I AC failure detect input
19 NC O No Connection (Output L)
20 NC O No Connection (Output L)
21 NC O No Connection (Output L)
22 NC O No Connection (Output L)
23 NC O No Connection (Output L)
24
NC O No Connection (Output L)
25 NC O No Connection (Output L)
26 NC O No Connection (Output L)
27 NC O No Connection (Output L)
28 NC O No Connection (Output L)
29 NC O No Connection (Output L)
30 NC O No Connection (Output L)
31 FL_OUT O Output data for flash writing
(Output data to writer)
32 FL_IN I/O Input data for flash writing
(Input data from writer)
33 FL_CLK I/O Clock signal for flash writing
(Clock signal from writer)
34 FL_BUSY O Busy signal for flash writing
(Busy signal to writer)
35 AV_DO O Data output to DVD OPECON
36 AV_DI I Data input from DVD
OPECON
37 AV_CLK I Clock input from DVD
OPECON
38 AV_CS O Chip select signal from DVD
OPECON
39 JOG_B I Signal B from Volume JOG
40 JOG_A I Signal A from Volume JOG
41 /EPM I/O For flash micro-p (Pull to
GND with resistor)
42 NC O No Connection (Output L)
43 NC O No Connection (Output L)
44 NC O No Connection (Output L)
45 NC O No Connection (Output L)
46 CE I/O For flash micro-p (Pull to
VCC with resistor)
47 PH_SW I Headphone detection switch
(H=Phone In)
48 NC O No Connection (Output L)
49
TUNER_CTF
O Tuner signal selection switch
(H=select TUNER)
50 DVD_CTR O DVD signal selection switch
(L=select DVD)
83
