9.1. Caution
Below is the list of disassembly sections
Below shown is part no. of different screws types used:
9 Assembling and Disassembling
“ATTENTION SERVICER”
Some chassis components may have sharp edges. Be careful when disassembling and servicing.
1. This section describes procedures for checking the operation of the major printed circuit boards and replacing the main
components.
2. For reassembly after operation checks or replacement, reverse the respective procedures.
Special reassembly procedures are described only when required.
3. Select items from the following index when checks or replacement are required.
4. Refer to the Parts No. on the page of “Parts Location and Replacement Parts List” (Section 21), if necessary.
Warning :-
This product uses a laser diode. Refer to caution statement Precaution of Laser Diode.
· Disassembly of Rear Cabinet
· Disassembly of D-Port P.C.B.
· Disassembly of Panel P.C.B. & LCD P.C.B.
· Disassembly of Main P.C.B., Sensor P.C.B., Tuner P.C.B.
· Disassembly of CD Servo P.C.B. & Switch P.C.B.
· Disassembly of Power Switch P.C.B. & Tact Switch P.C.B.
· Replacement of Traverse Cover
· Disassembly of CD Servo P.C.B.
· Disassembly of Motor Unit & Motor P.C.B.
· Disassembly of CD Block & CD Lid
· Disassembly of Speaker
