Panasonic SC-EN37P User Manual

Notes:
Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 RDG0612 PULLEY GEAR [M]
2 RDGV0001 2ND GREAR [M]
3 RDGV0002 DRIVE GEAR [M]
4 RDGV0003 LID GEAR [M]
5 RFKPAEN25PS MOTOR ASS’Y [M]
6 REEV0150 CD SERVO FFC (22P) [M]
7 REEV0180 OPTION PORT FFC [M]
8 RFKLAEN37P-K CD LID ASS’Y (A/B) [M]
8-1 RDPV0001 LID ROLLER [M]
8-2 RMG0699-KJ LID CUSHION [M]
8-3 RHD14136 SCREW [M]
9 RFKGAEN37P-K FRONT PANEL ASS’Y [M]
10 RGKV0165-K FRONT ORNAMENT [M]
11 RGPV0093-K LCD PANEL [M]
12 RGPV0094-K SENSOR PANEL [M]
13 RGUV0173-S POWER BUTTON [M]
14 RGUV0174B-S FUNCTION BUTTON [M]
15 RGUV0175-K VOL/SKIP BUTTON [M]
16 RHD26046-L SCREW [M]
17 RKA0162-KJ LEG RUBBER [M]
18 RKQV0052-K CD BASE [M]
19 RKSV0038G-K REAR CABINET [M]
20 RMAV0042 TRANS ANGLE [M]
21 RMG0268-K1 BELT [M]
22 RMKV0065 ROLLER GUIDE L [M]
23 RFKNAEN37P-K GEAR BASE ASS’Y [M]
24 RMKV0066 ROLLER GUIDE R [M]
25 RMLV0001 SW LEVER [M]
26 RMNV0080 LCD FIX PIECE [M]
27 RMNV0081 DC JACK HOLDER [M]
28 RMNV0082 LCD HOLDER [M]
29 RMNV0083 LED HOLDER [M]
30 RMNV0084 ANT HOLDER [M]
31 RMQV0077 GEAR FIXTURE [M]
32 RMSV0001 LID BEARING [M]
33 RMXV0032 LCD SPACER SHEET [M]
34 RMY0362J IC HEAT SINK [M]
35 RMYV0067 HEAT SINK [M]
Ref. No. Part No. Part Name & Description Remarks
36 RSC0732J EARTH PLATE [M]
37 RSC0733J TUNER SHIELD [M]
38 XTN2+6GFJ SCREW [M]
39 XTV3+12GFJK TOP CAB SCREW [M]
40 XYN26+C6FJ SCREW [M]
SPEAKERS
71 RFKHBEN37PKL SPEAKER CAB. ASS’Y L [M]SB-
EN37A
71 RFKHBEN37PKR SPEAKER CAB. ASS’Y R [M]SB-
EN37
71-1 K2GY2C000001 DC IN CABLE [M]SB-
EN37A
72 RFAX0011-KJ LEG FELT [M]
73 RKPV0048-K SP FRONT CABINET [M]
74 RYBV0046 PREPARED NET FRAME [M]
75 EAS8P198B SPEAKER [M]
76 RYTV0003 SP PORT UNIT [M]
77 XTV3+12GFJ-M SCREW [M]
78 XTV3+6FFJ SCREW [M]SB-
EN37A
TRAVERSE DECKS
301 RAE0165T-V TRAVERSE (W/O CD SERVO
P.C.B.)
[M]
302 RMR1396-K TRV COVER [M]
303 RMS0757-1 FIXED PIN [M]
304 RME0109 FLOATING SPRING [M]
305 RMG0730-G FLOATING RUBBER [M]
306 XTN2+6GFJ SCREW [M]
307 RMR1395-X MIDDLE CHASSIS [M]
PRINTED CIRCUIT BOARDS
REPV0111A CD SERVO P.C.B. [M](RTL)
REPV0136A TUNER P.C.B. [M](RTL)
REPV0136A MAIN P.C.B. [M](RTL)
REPV0136A PANEL P.C.B. [M](RTL)
REPV0129A D-PORT P.C.B. [M](RTL)
21 Replacement Parts List
· Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthe rmore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
· The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
· Warning: This product uses a laser diode. Refer to caution statements on “Precaution of Laser Diode”.
· Capacitor values are in microfarads (µF) unless specified otherwise, P= Pico-farads (pF), F= Farads.
· Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
· The marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
· [M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
· Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine
65
SC-EN37P
