Ref. No. Part No. Part Name & Description Remarks
REPV0136A LED P.C.B. [M](RTL)
REPV0136A POWER SWITCH P.C.B. [M](RTL)
REPV0136A TACT SWITCH P.C.B. [M](RTL)
REPV0136A SWITCH P.C.B. [M](RTL)
REPV0136A MOTOR P.C.B. [M](RTL)
REPV0136A SENSOR P.C.B. [M](RTL)
REPV0136A TRANSFORMER P.C.B [M](RTL)
INTEGRATED CIRCUITS
IC1 C1BB00001120 IC TUNER [M]
IC301 C1BB00000732 IC AUDIO SOUND PROCESSOR [M]
IC351 C0GAE0000007 IC MOTOR DRIVER [M]
IC601 C0AAAA000036 IC POWER [M]
IC602 C0DAEKG00002 IC REGULATOR [M]
IC801 MN101EF16ZXW IC MICON [M]
IC1001 C0HBA0000238 IC LCD DRIVER [M]
IC3001 C0ABBB000297 IC DUAL OP-AMP [M]
IC3002 C0JBAB000884 IC LOGIC [M]
IC3003 C0CBCBC00090 IC 3.3V LDO [M]
IC7001 MN6627954MA IC SERVO
PROCESSOR/DIGITAL SIGNAL
PROCESSOR/DIGITAL FILTER
D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Q1 B1ABDF000026 TRANSISTOR [M]
Q2 B1ADCF000063 TRANSISTOR [M]
Q301 B1ADCF000063 TRANSISTOR [M]
Q401 B1ABGD000022 TRANSISTOR [M]
Q501 B1ABGD000022 TRANSISTOR [M]
Q601 B1ABDF000026 TRANSISTOR [M]
Q603 B1ACND000003 TRANSISTOR [M]
Q604 B1ABDF000026 TRANSISTOR [M]
Q605 B1BCCG000002 TRANSISTOR [M]
Q606 B1ADCF000063 TRANSISTOR [M]
Q607 B1ABDF000026 TRANSISTOR [M]
Q608 B1ACND000003 TRANSISTOR [M]
Q611 B1ACND000003 TRANSISTOR [M]
Q612 B1ABDF000026 TRANSISTOR [M]
Q613 B1ADCF000063 TRANSISTOR [M]
Q615 B1BAAJ000003 TRANSISTOR [M]
Q617 B1ABDF000026 TRANSISTOR [M]
Q622 B1ACND000003 TRANSISTOR [M]
Q623 B1ABDF000026 TRANSISTOR [M]
Q801 B1ABDF000026 TRANSISTOR [M]
Q802 B1ABDF000026 TRANSISTOR [M]
Q3001 B1ADCE000012 TRANSISTOR [M]
Q3002 B1ABEB000002 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
QR609 UNR521400L TRANSISTOR [M]
QR614 B1GBCFGJ0016 TRANSISTOR [M]
QR618 B1GBCFGJ0016 TRANSISTOR [M]
QR619 B1GBCFGJ0016 TRANSISTOR [M]
QR621 UNR511100L TRANSISTOR [M]
QR803 UNR521300L TRANSISTOR [M]
QR804 UNR511100L TRANSISTOR [M]
QR3001 B1GBCFGN0016 TRANSISTOR [M]
QR3002 B1GBCFGN0016 TRANSISTOR [M]
QR3003 B1GBCFGN0016 TRANSISTOR [M]
QR3004 B1GBCFGN0016 TRANSISTOR [M]
DIODES
D1 B0CDAD000010 DIODE [M]
D2 B0CDAB000019 DIODE [M]
D3 B0CDAB000019 DIODE [M]
D4 B0AACK000004 DIODE [M]
D602 B0EAKM000117 DIODE [M]
D603 B0EAKM000117 DIODE [M]
D604 B0EAKM000117 DIODE [M]
Ref. No. Part No. Part Name & Description Remarks
D605 B0AACK000004 DIODE [M]
D607 B0AACK000004 DIODE [M]
D608 B0BA8R700009 DIODE [M]
D610 B0AACK000004 DIODE [M]
D611 B0AACK000004 DIODE [M]
D612 B0ACCE000003 DIODE [M]
D613 B0ACCE000003 DIODE [M]
D614 B0BA6R100003 DIODE [M]
D615 B0BA4R600003 DIODE [M]
D616 B0EAKM000117 DIODE [M]
D621 B0AACK000004 DIODE [M]
D622 B0BA5R000004 DIODE [M]
D801 B0AACK000004 DIODE [M]
D802 B0AACK000004 DIODE [M]
D803 B0ACCE000003 DIODE [M]
D901 B0EAMM000038 DIODE [M]
D902 B0EAMM000038 DIODE [M]
D903 B0EAMM000038 DIODE [M]
D904 B0EAMM000038 DIODE [M]
D1001 B0BA7R900004 DIODE [M]
D1005 LNG4A4CN4E DIODE [M]
D1007 B0BA6R100003 DIODE [M]
D7650 MAZ80560ML DIODE [M]
SWITCHES
S351 K0L1BA000078 SW CD TOP [M]
S352 K0L1BA000078 SW CD BOTTOM [M]
S801 EVQ21405RJ SW POWER [M]
S802 EVQ21405RJ SW VOL - [M]
S803 EVQ21405RJ SW VOL + [M]
S804 EVQ21405RJ SW REV_SKIP [M]
S805 EVQ21405RJ SW FWD_SKIP [M]
S806 EVQ21405RJ SW TUNER/XM [M]
S807 EVQ21405RJ SW CD [M]
S808 EVQ21405RJ SW MUSIC_PORT [M]
S809 EVQ21405RJ SW STOP [M]
S810 EVQ21405RJ SW CD_OP/CL [M]
S7201 RSH1A048-A SW RESET [M]
CONNECTORS
CN801 K1MN06A00013 6P FFC CONNECTOR [M]
CN806A K1MN13BA0147 13P CONNECTOR [M]
CN2401 K1FY124DA001 24P CONNECTOR [M]
CN7001 K1MN16B00154 16P FFC CONNECTOR [M]
CN7002 K1MN22BA0005 22P CONNECTOR [M]
FP701 K1MN22B00014 22P FFC CONNECTOR [M]
FP806 K1KZ13A00001 13P CONNECTOR [M]
P1 K1KA03BA0125 3P CONNECTOR [M]
P351 K1MP05B00004 5P CONNECTOR [M]
P352 K1MP03B00004 3P CONNECTOR [M]
P601 K1MP06B00009 6P CONNECTOR [M]
P801 K1MP09B00004 9P CONNECTOR [M]
P802 K1KA02BA0125 2P CONNECTOR [M]
COILS & TRANSFORMERS
L1 G0ZZ00002353 FM COIL [M]
L3 G0ZZ00002353 FM COIL [M]
L5 G0ZZ00002453 FM OSC COIL [M]
L7 G2BPC0000017 AM OSC COIL [M]
L8 G0C101KA0029 AXIAL COIL [M]
L51 G2A390C00001 AM RF-COIL [M]
L101 ERJ3GEY0R00V CHIP JUMPER [M]
L201 ERJ3GEY0R00V CHIP JUMPER [M]
L301 ERJ3GEY0R00V CHIP JUMPER [M]
L304 J0JBC0000019 CHIP INDUCTOR [M]
L401 ERJ3GEY0R00V CHIP JUMPER [M]
L403 ERJ3GEY0R00V CHIP JUMPER [M]
L404 ERJ3GEY0R00V CHIP JUMPER [M]
L501 ERJ3GEY0R00V CHIP JUMPER [M]
66
SC-EN37P
