8.2. Music Port
With reference to page 31 of the operating instruction manual.
Condition Explanation
Change The state when one of the opened tray being driven from OPEN position to STOCK position and other
opene
d trays remain still at OPEN position.
Close All The state where all open trays will being driven from OPEN position to STOCK position, one by one from
to
p to bottom
Note:
* represent tray number (from 1 ~ 5)
8.1.4. New CD Mechanism (CRS1D)
Note:
Thi
s service manual does not contain the following information for the mention CD/DVD Mechanism drive:
•• Schematic Diagram, Block Diagram and P.C.B. layout of CD/DVD Loading P.C.B.
•• Part List for individual parts of the mechanism.
•• Exploded View and Parts List for individual parts of the CD/DVD Mechanism drive.
Pleas
e refer to the original service manual (Order No. MD0603065A3) for the CD/DVD Mechanism Drive CRS1D.
