Panasonic SC-TM760 - Disassembly of Deck Mechanism

* The mechanism as shown below is for DECK1. For DECK
2, perform the same procedures.
11.18. Disassembly of Deck Mechanism
· Follow the (Step 1) - (Step 2) of Item 10.4 - Disassembly of Top Cabinet
· Follow the (Step 1) - (Step 4) of Item 10.6 - Disassembly of CD Changer Unit
· Follow the (Step 1) - (Step 4) of Item 10.10 - Disassembly of Front Panel Unit
· Follow the (Step 1) - (Step 5) of Item 10.12 - Disassembly of Deck Mechanism Unit
11.18.1. Disassembly of the pinch roller ass’y and head block
