Panasonic TH-50LFE7U - Parts List

34
TH-50LFE7U/TH-50LFE7W/TH-50LFE7E
10.3. Parts List
Safety Ref. No. Part No. Part Name & Description Pcs Remarks
1 TBX5ZA03301 KEY BUTTON BRACKET 1
2 TKK5ZC50501A LED PANEL 1
3 TKP5ZA41701 LED PANEL CASE 1
4 TKP5ZA41401 SP BRACKET 2
5 TMM23417 SPACER 1
6 TMME399 SPACER 2 (P2)
7 TQF0AA122 MODEL NUMBER LABEL 1
8 VUM50TERKIT TERMINAL METAL 1 Incl. (FELT)
9 TUX5ZX0321 VESA METAL 4
10 TUX5ZX0381 BOTTOM METAL 2
11 TTU0AA0177 BACKCOVER COMP 1 U
11 TTU0AA0184 BACKCOVER COMP 1 W
11 TTU0AA0183 BACKCOVER COMP 1 E
THEC1509 SCREW 16 (BC16)
THEC2359 SCREW 2 (BC2)
THTD037J SCREW 5 (SP4/CTRL1)
THEA068N SCREW 6 (SERIAL2/PC2/DVI2)
THEJ036J SCREW 29 (A5/P5/SP4/VE4/BTM4/HDMI2/AM2/TM3)
12 VVM50PAEKIT LCD PANEL ASSY 1 Incl. (AL-TAPE/PET-TAPE/FELT/DOUBLE COATED TAPE)
13 VVM50SPEKIT SPEAKER UNIT 2 Incl. (SPONG)
14 TSCKF0170136 LVDS CABLE 1
TXJ/A21KJJ LEAD 1 A2-P2
TXJ/P41KJJ LEAD 1 P4-LD1
TXJ/P51KJJ LEAD 1 P5-GK4
TXJA101KJJ LEAD 1 A10-K10
TXJA131KJJ LEAD 1 A13-SP
15 TQB0AC0097-1 INSTRUCTION BOOK 1 U (ENG/SPA/FRA)
15 TQB0AC0102-1 INSTRUCTION BOOK 1 W (ENGLISH)
15 TQB0AC0103-1 INSTRUCTION BOOK 1 W (ARABIC)
15 TQB0AC0098-2 INSTRUCTION BOOK 1 E (ENG/FRA/SPA)
15 TQB0AC0099-2 INSTRUCTION BOOK 1 E (GER/ITA)
15 TQB0AC0100-2 INSTRUCTION BOOK 1 E (SWE/NOR/FIN)
15 TQB0AC0101-1 INSTRUCTION BOOK 1 E (RUS/UKR/KAZ)
16 TQB0AC9004-1 INSTRUCTION BOOK 1 U (CD-ROM)
16 TQB0AC9005-1 INSTRUCTION BOOK 1 E (CD-ROM)
17 K2CA2YY00262 AC CORD 1 U
17 K2CJ2YY00084 AC CORD 1 W
17 K2CQ2YY00107 AC CORD 1 W / E
17 K2CT2YY00089 AC CORD 1 W / E
18 N2QAYB000691 REMOTE CONTROL UNITS 1
19 TPC0AA09511 CARTON 1 U
19 TPC0AA09513 CARTON 1 W
19 TPC0AA09512 CARTON 1 E
20 TPD0AA02371 CUSHION TOP 1
21 TPD0AA02381 CUSHION BOTTOM 1
22 TPD0AA02411 CUSHION FRONT 1
23 TPE0AH023 SET BAG 1
24 TZTNP011KJJ CIRCUIT BOARD (A) 1 Incl. (GASKET)
25 TXN/K1TQUK CIRCUIT BOARD (K) 1
26 VVM50POWKIT CIRCUIT BOARD (P) 1 Incl. (FELT)
27 TXNGK11LJJ CIRCUIT BOARD (GK) 1
