Panasonic TH-55AF1U - Preset Signals

English
110
Preset Signals
This unit can display the video signals shown in the table below.
■ Video signal
Corresponding signal Resolution (Dot)
Scanning frequency Dot clock
frequency
(MHz)
Format
*
3
Horizontal (kHz) Vertical (Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 × 480i
15.7 59.9
- V
PAL/PAL-N/SECAM 720 × 576i
15.6 50.0
- V
525i(480i) 720 × 480i
15.7 59.9
13.5 R/Y
625i(576i) 720 × 576i
15.6 50.0
13.5 R/Y
525i(480i) 720(1440) × 480i
*
2
15.7 59.9
27.0 D/H
625i(576i) 720(1440) × 576i
*
2
15.6 50.0
27.0 D/H
525p(480p) 720 × 480
31.5 59.9
27.0 R/Y/D/H
625p(576p) 720 × 576
31.3 50.0
27.0 R/Y/D/H
750(720)/60p 1 280 × 720
45.0 60.0
74.3 R/Y/D/H
750(720)/50p 1 280 × 720
37.5 50.0
74.3 R/Y/D/H
1 125(1 080)/60i
*
1
1 920 × 1 080i
33.8 60.0
74.3 R/Y/D/H
1 125(1 080)/50i 1 920 × 1 080i
28.1 50.0
74.3 R/Y/D/H
1 125(1 080)/24p 1 920 × 1 080
27.0 24.0
74.3 R/Y/D/H
1 125(1 080)/24PsF 1 920 × 1 080i
27.0 48.0
74.3 R/Y
1 125(1 080)/25p 1 920 × 1 080
28.1 25.0
74.3 R/Y/D/H
1 125(1 080)/30p 1 920 × 1 080
33.8 30.0
74.3 R/Y/D/H
1 125(1 080)/60p 1 920 × 1 080
67.5 60.0
148.5 R/Y/D/H
1 125(1 080)/50p 1 920 × 1 080
56.3 50.0
148.5 R/Y/D/H
■ PC signal
Corresponding signal Resolution (Dot)
Scanning frequency Dot clock
frequency
(MHz)
Format
*
3
Horizontal (kHz) Vertical (Hz)
640 × 400
*
6
640 × 400
31.5 70.1
25.2
R/Y/D/H
640 × 400
37.9 85.1
31.5
R/Y/D/H
640 × 480
*
6
640 × 480
31.5 59.9
25.2
R/Y/D/H
640 × 480
35.0 66.7
30.2
R/Y/D/H
640 × 480
37.9 72.8
31.5
R/Y/D/H
640 × 480
37.5 75.0
31.5
R/Y/D/H
640 × 480
43.3 85.0
36.0
R/Y/D/H
800 × 600
*
6
800 × 600
35.2 56.3
36.0
R/Y/D/H
800 × 600
37.9 60.3
40.0
R/Y/D/H
800 × 600
48.1 72.2
50.0
R/Y/D/H
800 × 600
46.9 75.0
49.5
R/Y/D/H
800 × 600
53.7 85.1
56.3
R/Y/D/H
832 × 624
*
6
832 × 624
49.7 74.6
57.3
R/Y/D/H
852 × 480 852 × 480
31.5 59.9
34.2
D/H
1 024 × 768
*
6
1 024 × 768
39.6 50.0
51.9
D/H
1 024 × 768
48.4 60.0
65.0
R/Y/D/H
1 024 × 768
56.5 70.1
75.0
R/Y/D/H
1 024 × 768
60.0 75.0
78.8
R/Y/D/H
1 024 × 768
65.5 81.6
86.0
R/Y/D/H
1 024 × 768
68.7 85.0
94.5
R/Y/D/H
1 066 × 600 1 066 × 600
37.6 59.9
53.0
D/H
1 152 × 864
*
6
1 152 × 864
53.7 60.0
81.6
R/Y/D/H
1 152 × 864
64.0 70.0
94.2
R/Y/D/H
1 152 × 864
67.5 74.9
108.0
R/Y/D/H
1 152 × 864
77.1 85.0
119.7
R/Y/D/H
1 152 × 870
*
6
1 152 × 870
68.7 75.1
100.0
R/Y/D/H
1 280 × 720
*
6
1 280 × 720
44.8 59.9
74.5
R/Y/D/H
