159
Printing Journals
and Lists
Explanation of Contents
(1) Indication of Communication
Mode
(2) Start Time of Communication
(3) End Time of Communication
(4) File Number : 001 to 999 (When the communication is stored into memory, a file number is
assigned for each communication.)
(5) Station Number : Sequential number of the Stations.
(6) Communication Result : "OK" indicates that the communication was successful.
"BUSY" indicates that the communication has failed because of busy line.
"STOP" indicates that STOP was pressed during communication.
"P-OK" indicates that memory overflow occurred while storing the documents
into memory for transmission but successfully stored document(s) was sent.
"R-OK" indicates that the Relayed XMT was successful.
"B-OK" indicates that the Batch Transmission was successful.
"- -" indicates LAN transmission.
"3-digit Info Code" (see page 168) indicates that the communication has
failed. In this case, the machine will print the attached report with first page of
your document as shown on the previous page.
(7) One-Touch/Abbreviated Number
or
Symbol
: mark indicates dialed by direct number dialing.
(8) Recorded Name in the Phone
Book, Direct Dialing Number, or
Email Address
(9) Number of Pages Transmitted or
Received
: The 3-digit number is the number of pages successfully transmitted or
received.
When the documents are stored into memory, two 3-digit numbers will
appear.
The first 3-digit number represents the number of pages successfully
transmitted.
The second 3-digit number represents the total number of pages that were
attempted to be transmitted.
(10) Duration of Communication
