Appendix

For Email (Internet Fax)

Standard Compliance 10Base-T Ethernet (IEEE 802.3), 100Base-TX Fast Ethernet (IEEE802.3u)

Connector Interfaces 10/100Base-TX port: RJ-45

Compatibility IETF RFC 2305, ITU-T T.37

Communication Protocol TCP/IP, SMTP, POP3, MIME

File Format TIFF [IETF RFC 2301 Profile S, F, J]

PDF (Transmission only)

Email Receiving Width Maximum Ledger size

Options and Supplies

Part Name Part No. Remarks

Verification Stamp DZHT000027 (for USA and Canada)

DZHT000004 (for other countries)

X-Stamp

Expansion Flash Memory Card UE-410047

UE-410048

4 MB Flash Memory Card

8 MB Flash Memory Card
