Pando PHT-941 - 1 Description of the Ove; 2 Control Panel

INOXPAN S.L. EN - 5
1
Control pane
2
Lock/door switch
(only for pyrolytic models)
3
Grill element
4
Tray runners
5
Grid shelf
6
Tray
7
Hinge
8
Inner pane
9
Air cooling outlet
10
Door switch
(only for NON-pyrolytic models)
11
Cabinet mounting
12
Light
13
Back wall panel
14
Fan
15
Oven seal
16
Door
1
Dial to scroll through the menus on the left side of the screen. Cooking mode dial.
2
Display screen.
3
Dial to scroll through the menus on the right side of the screen. Cooking settings dial.
4
Keys.
Switching the oven ON/OFF .
Altering the oven temperature.
Access to the personal Cooking
assistant (PANDO CHEF)
Activation / Deactivation of the Keypad /
door lock depending on the model.
Access to the timing and
programming settings.
Confirm button.
Switching the inner light on/off .
1. DESCRIPTION OF THE OVE
2. CONTROL PANEL
