Pantum BM5100ADW Series User Manual

XIII
11.1.6. Print a Page for Clean & Fix ..................................................................................... 127
11.1.7. Auto shut-off setting ................................................................................................. 128
11.2. Network Settings ............................................................................................................ 129
11.3. Network Information ....................................................................................................... 129
11.4. Print information report ................................................................................................... 130
11.5. Residual amount of toner ................................................................................................ 131
11.6. Online upgrade ............................................................................................................... 131
12. Routine Maintenance ............................................................................................................ 132
12.1. Cleaning the Printer ........................................................................................................ 132
12.2. Toner cartridge and drum component maintenance ........................................................ 137
12.2.1. About toner cartridge and drum component component ........................................... 137
12.2.2. Replace toner cartridge and drum component .......................................................... 138
12.3. Installing and removing the optional tray ......................................................................... 143
12.3.1. Installing optional tray .............................................................................................. 143
12.3.2. Removing the optional tray ....................................................................................... 145
12.3.3. Updating the optional tray status .............................................................................. 146
13.Troubleshooting ..................................................................................................................... 147
13.1. Cleaning Jammed Paper ................................................................................................ 147
13.1.1. Middle jam................................................................................................................ 147
13.1.2. Paper Jam in the Fuser Unit ..................................................................................... 150
13.1.3. Duplex Unit Jam ....................................................................................................... 154
13.1.4. A paper jam occurs on the automatic document feeder (ADF) ................................. 156
13.1.5. Paper jam of auto feed tray ...................................................................................... 158
13.1.6. Paper jam of multi-purpose tray ............................................................................... 159
13.1.7. Paper jam of optional tray ........................................................................................ 160
13.2. Software Failure ............................................................................................................. 164
13.3. Error Message ................................................................................................................ 165
13.4. Common Troubleshooting .............................................................................................. 166
13.4.1. Common Trouble ..................................................................................................... 166
13.4.2. Image Defects .......................................................................................................... 169
14. Menu Structure ..................................................................................................................... 173
15. Product Specifications ........................................................................................................... 174

Pantum BM5100ADW Series Specifications

General

Print Technology	Monochrome Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Automatic
Connectivity	USB, Ethernet, Wi-Fi
Monthly Duty Cycle	100, 000 pages
Processor	1.2 GHz
Memory	512 MB
ADF Capacity	50 sheets
Scan Type	Flatbed, ADF
Fax Function	Yes
Input Capacity	250 sheets
Output Capacity	150 sheets
Printer Languages	PCL6, PostScript 3
Copy Resolution	600 x 600 dpi
Scan Resolution	1200 x 1200 dpi
First Print Out Time	6.9 seconds
Toner Yield	3, 000 pages
Mobile Printing	AirPrint, Mopria
Print Speed	40 ppm (A4) / 42 ppm (Letter)
Copy Speed	40 cpm (A4) / 42 cpm (Letter)
