Pantum M9106 Series - Installing Optional Tray; Install 2 X 500-Sheet Tray (Tray 3, Tray 4)

164 pages

To Next Page

To Previous Page

Installing optional tray

Note:

• If you want to buy this optional part, please contact the local distributor of the printer.

Install 2 x 500-sheet tray (tray 3, tray 4)

1. Power off the printer.

2. Unplug the power cord from the outlet, and then unplug the power cord from the printer.

3. Unpack the tray and remove all packaging materials.
